G GLENSOUND ELECTRONICS LTD
Date 07/02/01 Information Sheet Number WP14-85 Issue Number 1
Page 1 of 1
G GLENSOUND ELECTRONICS LTD. 5&6 BROOKS PLACE, MAIDSTONE, KENT, ENGLAND.
COMMENTATORS BOX TYPE GSOC26
ON AIR LOGIC TRUTH TABLE
Facilities are provided on Conn 2 to interface the On-Air LED on the commentators box
GSOC24 with external logic. ie: If the A, B & C Prefade outputs are fed to an external mixer,
contacts on mixer faders can be used to operate the On-Air LED.
It is possible to make the LED solely dependant on the faders or solely dependant on the
GSOC26 switch or as a function of both.
The available combinations are as follows:
CONN 2
PIN 11
CONN 2
PIN 23
FRONT
PANEL
IDENT SWITCH
GSOC24
ON AIR
LED
LINK TO PIN 24 = LOW LINK TO PIN 10 = LOW PLAY ON
LINK TO PIN 24 = LOW LINK TO PIN 10 = LOW NORMAL ON
LINK TO PIN 24 = LOW LEAVE O.C = HIGH PLAY OFF
LINK TO PIN 24 = LOW LEAVE O.C = HIGH NORMAL OFF
LEAVE O.C = HIGH LINK TO PIN 10 = LOW PLAY ON
LEAVE O.C = HIGH LINK TO PIN 10 = LOW NORMAL ON
LEAVE O.C = HIGH LEAVE O.C = HIGH PLAY OFF
LEAVE O.C = HIGH LEAVE O.C = HIGH NORMAL ON
