4
STEP 4
Attach steel plate (P) to top panel (A) with screw (L) using screwdriver. Place assembled
unit in desired position. Mark position of steel plate (P) on wall and remove unit. Drill one
hole on the wall and then put wall anchor (N) into the predrilled hole. Attach steel plate (P)
to wall anchor (N) with screw (O) using screwdriver. Place unit back into position. Attach
anti tipping strip (M) to steel plates (P) as shown.
After initial assembly, the product may
acclimate to its new environment.
Please ensure all screws are still
securely tightened.
O
WALL
P
NOT INCLUDED
M
NOT INCLUDED
WALL
N
NOT INCLUDED
L
M
L x 1 M x 1 N x 1 O x 1 P x 2
