will be opened.
4) Control command format
If user want to write his own control software, below are data format and baud rate setting.
Com port setting:
Baud Rate:
9600 bps
Data bits:
8 bits
Parity:
None
Stop bits:
1 bit
Flow control:
None
5) RS232 command
command
feedback
description
cir_0x\r\n
s1y
Output 1 select input 1~8
“x” : indicate the input port, range
from 0~7.
“y” : indicate the input port, range
from 1~8.
cir_1x\r\n
s2y
Output 2 select input 1~8
“x” : indicate the input port, range
from 0~7.
“y” : indicate the input port, range
from 1~8.
cir_2x\r\n
s3y
Output 3 select input 1~8
“x” : indicate the input port, range
from 0~7.
“y” : indicate the input port, range
from 1~8.
cir_3x\r\n
s4y
Output 4 select input 1~8
“x” : indicate the input port, range
