■ Package Contents
① 1x Main unit. P/N_ MX88.
② 1x Remote.
③ 1x RS232 cable
④ 12V/DC Power Supply. P/N_VDC01205.
⑤ 1x CD-ROM(Control software operating instructions).
⑥ Mounting ears.
NOTE: PART NUMBER (Abbreviation as P/N).
■ Panel Descriptions
① OUT1—8: HDMI output .
② IR : IR receive.
③ IN1—8: HDMI input .
④ ALL: HDMI output 1--8
⑤ LOCK: Press this button to lock all the functions and press it again to release
the lock.
① RS232 port.
② LAN port.
③ HDMI output port.
④ HDMI input port (HDMI or DVI).
⑤ Power: Press this button to turn the system on.
⑥ IR extender: This slot is where you can extend your IR receiver with an IR
To Next Page
