Rule #4
Wherever possible "balance" the layout by using the same size and type of overhead storage unit on both sides of the same panel.
This type of layout will ensure strait panel runs.
Rule #5
48" and 60" wide overhead storage units require corner posts and wing panels on both sides of the supporting panel.
Rule #6
A run of panels without worksurfaces should be no longer than 9'-0" and must be supported with (A) wing panels at both ends, (B) a wing panel at one
end and a Self-Supporting Foot (EESF-1) at the other end, or (C) (not shown) a wing panel at one end and a Floor Mount (EEFM) at the other end. Note:
Floor Mounts must be bolted to the floor.
