ELECTRIC SCOOTER
E-23
FRANÇAIS
9
7 BATTERY DISASSEMBLE AND ASSEMBLE INSTRUCTIONS
Disassemble
1. Press the dashboard cover lock to
open it, then pull it up.
1. Open the dashboard cover and
battery cover.
Tip: Lightly press the cover and turn.
2. Unscrew the battery cover.
Tip: Lightly press the cover
and turn.
2. Align the groove of the battery
with the groove of the column
and gently place the battery
inside (please pay attention to the
direction of the groove).
Assemble
3. Pull the battery straight up to
remove the battery.
Then tighten the battery cover.
3. Tighten the battery cover
and push the dashboard cover
lock down.
Warning. To properly tighten the
cover, make sure that the strap
of the battery does not block the
mechanism.
Warning. Before repositioning the battery in its housing, be sure to replace the protective cap of the charging port
located under the battery to avoid faulty contact (see the loading scheme of Option 2).
8 CHARGING
Your electric scooter is delivered with a specic charger.
It is also equipped with two loading ports:
- 1 loading port located at the base of the steering column.
- 1 charging port located at the base of the battery (removable battery).
Both of these charging options meet a practical need and allow battery charging in all circumstances.
Option 1: Charging the battery directly on the scooter
1. To charge your electric scooter, remove the waterproof cap from the port on the back of the scooter's steering column and
plug in the charger. For safety reasons, ensure the charging port is always dry before starting to charge.
2. Plug the charger into a suitable power source.
3. When LED on the charger is red, the battery is charging.
4. When it switches to green, charging is complete or disconnected. This takes approximately 3 hours. Stop charging when
the diode turns green; charging the battery for too long will reduce its lifetime.
ENGLISH
