3.2 Elements of the device
A Ergonomic handle
B Charging status indicator
C Battery: 18.0 V / 4.0 Ah (NOT includ-
ed in item 000297.0000)
D ON/OFF safety switch
E Additional handle
F Telescopic tube
G Screw connection telescopic tube
H Safety guard for joint brush
I Guiding wheel
J Joint brush unit
K Locking device (2 x left/right)
L Motor/gear unit
M Guide arm (removable)
N Surface brush
O Adjustable safety guard
P Drive arm (removable)
Q Lock button
R Charging station (NOT included in
item 000297.0000)
S Adjustment wheel for speed control
(Speed control)
4 Technical data
MultiBrush li-on
Set – Item number(s): 000297.0000
(battery and charger not included)
Battery (NOT included in item 000297.0000)
Type: Lithium-ion (Bosch PBA 18V 4.0 Ah)
Nominal voltage: 18.0 V
Rating: 4.0 Ah
Charging station (AL 1810 CV) (NOT included in item 000297.0000)
Input: 220-240 V~ / 50/60 Hz
Output: 14.4-18 V / DC / 1.0 A
Battery charging time (100%): 244 Min.
Per. charging temp. range: 0 – + 45 °C
Protection class: II
(These following rights apply to the AL 1810 CV charger)
Dimensions & Rotational speeds
Device width: Surface brush 24.0 cm // Joint brush 28 cm
Device height (min): Surface brush 1.15 m // Joint brush 1.04 m
Device height (max): Surface brush 1.35 m // Joint brush 1.24 m
Rotational speed of joint brush: 630-1260 rpm
Rotational speed of surface brush: 450-900 rpm
Device weight with joint brush: 2.7 kg without battery / 3.4 kg with battery
Device weight with surface brush: 3.4 kg without battery / 4.1 kg with battery
Protection class: II
