Glow-worm 30si Instructions For Use, Installation & Servicing

Supplied By www.heating spares.co Tel. 0161 620 6677
11
4000123434-2
1 Technical Data
Heat input (max) NET Q 32,6 kW
111,231 BTU/H
Heat input (min) NET Q 13,3 kW
45,380 BTU/H
Heat output (max) NET P 29,6 kW
100,995 BTU/H
Heat output (min) NET P 10,8 kW
36,849 BTU/H
Efficiency - Sedbuk D 78,6%
Maximum heating temperature 87° C
Expansion vessel effective capacity 5 litres
Expansion vessel charge pressure 0,5 bar
Maximum system capacity at 75°C 156 litres
Safety valve, maximum service pressure 3 bar
Heating
Heat input (max) NET Q 32,6 kW
111,231 BTU/H
Heat input (min) NET Q 13,3 kW
45,380 BTU/H
Heat output (max) NET P 29,6 kW
100,995 BTU/H
Heat output (min) NET P 10,8 kW
36,849 BTU/H
Maximum hot water temperature 60 °C
Minimum hot water temperature 38 °C
Specific flow rate (for 30°C temp rise) 17 litres/min.
Threshold flow rate 1,7 litres/min.
Maximum supply pressure 10 bar
Minimum supply pressure 0,5 bar
Hot water
Electrical supply 230 V ~ 50Hz
Electrical rating 130 W fused at 3A
Level of protection IPX4D
Fuse rating 1,25mA
Electrical
Products outlet diameter 60 mm
Fresh air inlet diameter 100 mm
Combustion products values CO (40 ppm)
CO2 (7,6%)
NOx (82ppm)
Combustion
Ø Burner injector 1,2 mm
Inlet pressure 20 mbar
Maxi. Burner pressure 11,3 mbar
Mini. Burner pressure 1,96 mbar
Gas rate maximum 3,25 m
3
/h
Natural Gas (G20)
Ø Burner injector 0,73 mm
Inlet pressure 29 mbar
Maxi. Burner pressure 25,5 mbar
Mini. Burner pressure 3,73 mbar
Gas rate maximum 2,57 kg/h
Butane Gas (G30)
Ø Burner injector 0,73 mm
Inlet pressure 37 mbar
Maxi. Burner pressure 32,5 mbar
Mini. Burner pressure 4,7 mbar
Gas rate maximum 2,53 kg/h
Propane Gas (G31)
30ci
30si
Heat input (max) NET Q 32,6 kW
111,231 BTU/H
Heat input (min) NET Q 13,3 kW
45,380 BTU/H
Heat output (max) NET P 29,6 kW
100,995 BTU/H
Heat output (min) NET P 10,8 kW
36,849 BTU/H
Efficiency - Sedbuk D 78,6%
Maximum heating temperature 87° C
Expansion vessel effective capacity 5 litres
Expansion vessel charge pressure 0,5 bar
Maximum system capacity at 75°C 156 litres
Safety valve, maximum service pressure 3 bar
Heating
Electrical supply 230 V ~ 50Hz
Electrical rating 130 W fused at 3A
Level of protection IPX4D
Fuse rating 1,25mA
Electrical
Products outlet diameter 60 mm
Fresh air inlet diameter 100 mm
Combustion products values CO (40 ppm)
CO2 (7,6%)
NOx (82ppm)
Combustion
Ø Burner injector 1,2 mm
Inlet pressure 20 mbar
Maxi. Burner pressure 11,3 mbar
Mini. Burner pressure 1,96 mbar
Gas rate maximum 3,25 m
3
/h
Natural Gas (G20)
Ø Burner injector 0,73 mm
Inlet pressure 29 mbar
Maxi. Burner pressure 25,5 mbar
Mini. Burner pressure 3,73 mbar
Gas rate maximum 2,57 kg/h
Butane Gas (G30)
Ø Burner injector 0,73 mm
Inlet pressure 37 mbar
Maxi. Burner pressure 32,5 mbar
Mini. Burner pressure 4,7 mbar
Gas rate maximum 2,53 kg/h
Propane Gas (G31)

Glow-worm 30si Specifications

General

Brand	Glow-worm
Model	30si
Category	Boiler
Language	English
