OPERATION EC 65
12/09 16
3. Crimp crimp contact
Insert wire (1) in the crimp contact.
Press the foot switch (2) until the crimp die is fully
closed (3).
The crimp die (4) opens automatically, the foot
switch (5) can be released.
Remove the crimp contact with crimped wire (6).
!
lights up in the case of
defective crimping. Consult the
FAULTS chapter.
4. Taking out of operation
Read counter (1) if necessary.
Switch off the EC 65 at the power switch (2)
(press 0).
Figure 15 Crimp crimp contact
Figure 16 Putting out of operation
