1
40L & 50L
VERTICAL
DIRECT DRIVE
AIR COMPRESSORS
EVAC40 & EVAC50
INSTRUCTION MANUAL
Black
Cyan
Magenta
Yellow
Code: EVAC40/50 IM
Date: 070912 Edition: 6 Op: DCR
Do not switch on
for the first time
without first
filling with oil.


Air discharged from
this unit is not
suitable for human
consumption.

Test the safety relief
valve daily.
Refer the instruction
manual.

Keep oil level as shown:
Use only oil grade
specified in instruction
manual.

To prevent build-up of
condensation, open
drain cock daily
When filter becomes
dirty or oily, clean or
replace filter. Refer to
instruction manual.


High voltage used on
this equipment. Switch
off power supply &
remove plug from mains
before removing any
covers. Ensure mains
outlet is adequately
rated for this unit.


Unit starts
automatically.
Switch off power supply,
remove plug & relieve
air pressure prior to
commencing service
tasks.

Read instruction manual
prior to starting unit.
This equipment
operates from
AC mains only.

Questions and Answers

  • C
    Carlos CruzJul 29, 2025
    What to do if my GMC Air Compressor has insufficient pressure?
    • Z
      Zoe CoxJul 29, 2025
      If your GMC Air Compressor has insufficient pressure or decreased outlet capacity, several factors could be the cause. Ensure the drain cock is closed; if open, switch off the unit immediately and close it. Inspect all air fittings for tightness and leaks, reconnecting quick-release fittings if necessary or replacing defective ones. For male or female fittings leaking around the thread, tighten with a spanner or reapply Teflon tape after examining the fitting's condition. Also, examine the air hose for any holes or tears and replace it if defective. A dirty air filter cartridge can also cause this issue, so clean or replace it.
  • D
    Danielle LeeAug 3, 2025
    Why is my GMC Air Compressor motor not running?
    • B
      Barbara CardenasAug 3, 2025
      If your GMC Air Compressor motor isn't running, is running too slow, or is becoming excessively hot, check the power supply first. Ensure the compressor is plugged directly into a 240V household power point and not an extension cord or power board. Do not use an extension cord with your air compressor, as a power fault or low supply voltage could be the cause.
  • D
    Donna ClarkeAug 8, 2025
    What to do if safety valve leaking on GMC Air Compressor?
    • J
      Joseph MclaughlinAug 8, 2025
      If the safety valve on your GMC Air Compressor is leaking, immediately shut off the compressor and stop using it. Do not continue using the unit with a leaking safety valve.
  • P
    paularobertsAug 13, 2025
    Why GMC Air Compressor consumes excessive oil?
    • K
      Kelly LeeAug 14, 2025
      Excessive oil consumption in your GMC Air Compressor can be due to several reasons. Ensure the oil level is correct. Also, check if the hole in the oil filling plug is blocked and clean it if necessary.
  • F
    Frederick FloresAug 18, 2025
    What causes vibration in GMC Air Compressor?
    • V
      Victoria KimAug 18, 2025
      Vibration or abnormal noise in your GMC Air Compressor can be due to a loose part.
  • C
    Charles Rivera MDAug 25, 2025
    What causes the main compressor to stick on a GMC Air Compressor?
    • D
      Diana LongAug 25, 2025
      If the main compressor on your GMC Air Compressor is sticking or tight, it is due to moving parts damaged by heat caused by insufficient lubrication.

Summary

Warranty Power Tools

Warning Labels Explained

Introduction

Environmental Protection

Description of Symbols

Specifications

General Safety Instructions

Additional Safety Rules for Air Compressors

Contents of Carton

Know Your Product

Unpacking

Assembly

Fitting the Wheels

Instructions for attaching the wheels to the compressor unit, including required accessories.

Handle Assembly

Steps for attaching the handle to the compressor unit, requiring specific hardware.

Oil

Pre-start Routine

To Start & Stop the Compressor

Operation

Troubleshooting

Maintenance

General Inspection

Cleaning

Power Cord Maintenance

GMC Customer Assist

GMC 40L Specifications

General IconGeneral
Power2.2 kW
Tank Capacity40 L
Maximum Pressure8 bar
Motor Power3 HP
Phase1
