GMC CRHD950CF - Product Component Identification

GB
7
Know your product
1. On/Off trigger switch
2. Soft grip handle
3. Forward/Reverse lever switch
4. SDS-PLUS
®
Chuck
5. 4-Function selector
6. Selector button
7. Auxiliary handle
8. Adjustable depth gauge
9. Adjustable depth gauge locking knob
10. Locking sleeve
11. SDS-PLUS
®
Chuck adaptor
12. Chuck key
13. 13mm Keyed chuck
14. Carbon brush cap
5
4
12
1
3
2
6810
13
7
11
14
9
