GMC DP250LS - Know Your Product

8
Know your product
1. Laser light on/off switch
2. Laser aperture (x2)
3. On/off switch
4. Pulley cover
5. Pulley cover knob
6. Base
7. Column
8. Table/Support Assembly
9. Table Lock
10. Belt (x1)
11. Belt Tension Knob
12. Keyed Chuck
13. Motor Head
14. Feed Handle
15. Depth Scale
16. Depth Locking Knob
17. Bevel Scale
18. Chuck Key
19. Hex Keys (3mm, 4mm, 5mm)
1
2
3
4
5
6
7
8
12
11
14
15
16
19
9
13
17
18
10
