GMC HBB-0412 - Machine Construction & Application; Specifications; Transportation and Installation

4
I. Machine construction & Application
This machine is driven by hydraulic system, and all steel welded machine construction with high intensity,
good appearance, compact, safe and reliable performance.This machine is suitable for the sheet metal
processing plants, electrical protection, automobile manufacturing and other thin sheet metal bending
processing, etc.
Need to fill up the oil tank with Shell #68HD hydraulic oil or equivalent. Please make sure ¾ full of the tank.
Need to change hydraulic oil every 3 months or sooner subject to how many hours the machine in use every
day.
II. Specifications
III.Transportation and Installation
Crane or forklift is recommended
To move the machine, please move with forklift slowly and carefully, especially pay attention.
The machine is lifted by crane or moved by forklift after the removal of pallet.
Model
HBB-0412
HBB-0410
HBB-0612
HBB-0610
HBB-0812
HBB-0810
HBB-1014
HBB-1010
Max.bending thickness
HBB-0412:12Ga.
HBB-0410: 10Ga.
HBB-0612:12Ga
HBB-0610:10Ga
HBB
-
0812: 12Ga
HBB-0810: 10Ga
HBB-1014:14Ga
HBB-1010:10Ga
Max.bending width 48” (1220mm) 72” (1830mm) 96” (2440mm)
120”(3050mm)
Angle(°),degree 0 ~135 0 ~135 0 ~135 0 ~135
Hydraulic cylinder stroke
= clamp opening
3” 3” 3” 3”
Hydraulic cylinder pressure
（MP）
15 15 15 15
Hydraulic cylinder speed(mm/s) 50-58 50-85 50-85 50-75
Motor working pressure (Mp) 12 12 9-13 16
Motor Speed range(rpm) <30 <30 <30 <30
Motor power(HP) 5HP 5HP 7-1/2HP 10HP
N.W./G.W. LBS 4310 / 4630 5100/5300 6280 /6620 7510/37950
Packing size, inch 81x42x67 105x42x67 128x42x67 153x42x67
