GMC LDP13B12 User Manual

9
Know your product
1. Laser light on/off switch
2. Laser aperture (x2)
3. On/off switch
4. Pulley cover
5. Base
6. Column
7. Rack
8. Rack Collar
9. Table/Support Assembly
10. Belts (x2)
11. Belt Tension Lever
12. Table Handle
13. Keyless Chuck
14. Extension Table
Locking Knobs (x4)
15. Motor Head
16. Feed Handle
17. Depth Gauge
18. Depth Scale/Lock
19. Table Lock
20. Bevel Scale
21. Hex Keys
10 1011
19
20
21
1 418
3
2
6
8
13
14
17
5
12
15
16
7
9

GMC LDP13B12 Specifications

General

Brand	GMC
Model	LDP13B12
Category	Drill
Language	English
