GMC MX1275 - Product Overview and Adjustments; Know Your Product

1. Trigger switch
2. Lock-off button
3. Motor housing
4. Main handle
5. Front handle
6. Bevel adjustment knob
7. Bevel scale
8. Parallel fence locking knob
9. Parallel fence
10. Blade guard lever
11. Retracting blade guard
12. Base plate
13. Fixed blade guard
14. Dust extraction port
15. Depth locking lever
16. Cut depth indicator
17. Spindle lock button
18. Blade
19. Blade key storage area
20. Hex key
21. Sighting notch
