Know your product
1. Saw blade
2. Upper wheel housing
3. Saw band tensioning knob
4. Lower wheel housing
5. Saw band tensioning knob
6. Motor shaft (not shown)
7. Drive belt (not shown)
8. ON button
9. OFF button
10. Table insert
11. Rip fence
12. Rip fence scale
13. Rip fence guide
14. Rip fence guide handle
15. Table trunnion
16. Table trunnion bracket
17. Table tilt securing knob
18. 90º table tilt adjustable screw stop
19. Dust extraction port
20. Height adjustment knob
21. Blade support head
22. Table
23. Housing lock screws
7
3
9
21
1
11
22
13
2
10
23
8
12
14
4
5
15
18
16
17
20
