GMC RT200 - Component Identification

8
Know your product
Before using the router table,
familiarise yourself with all the
operating features and
safety requirements.
1. Table
2. Left table leg
3. Right table leg
4. Table inserts (x3)
5. On/off switch
6. Switch disabling insert
7. Rear fence
8. Adjustable fence bracket
9. Infeed fence
10. Outfeed fence
11. Fence locking knobs
12. Outfeed fence
locking knob
13. Guard
14. Mitre gauge
15. Mitre gauge lock knob
16. Dust extraction port
17. Starting pin
