D1054 - SIL 2 Repeater Power Supply and Trip Amplifiers G.M. International ISM0067-18
General Description: The single channel DIN Rail Repeater Power Supply and Trip Amplifier D1054S, provides a fully floating dc supply for energizing conventional 2 wires 4-20 mA
transmitters, or separately powered 3, 4 wires 4-20, 0-20 mA transmitters located in Hazardous Area, and repeats the current in floating circuit to drive a Safe Area load. Output signal
can be direct or reverse. The circuit allows bi-directional communication signals, for Hart-Smart transmitters. Two independent Alarm Trip Amplifiers are also provided. Each alarm
energizes, or de-energizes, an SPST relay for high, low, low-startup or burnout alarm functions. The two alarm relays trip points are settable over the entire input signal range.
Function: 1 channel I.S. analog input for 2 wires loop powered or separately powered Smart transmitters, provides 3 port isolation (input/output/supply) and current (source mode) or
voltage output signal. In addition it provides two SPST relay alarm contacts with adjustable alarm trip point.
Signalling LEDs: Power supply indication (green), burnout (red), alarm A (red), alarm B (red).
Configurability: Totally software configurable, no jumpers or switches, mA or V output signal, linear or reverse, alarm trip point, high, low, low-startup or burnout alarm mode, NE/ND
relay operation, hysteresis, delay time, by GM Pocket Portable Configurator PPC1090, powered by the unit or configured by PC via RS-232 serial line with PPC1092 Adapter and
SWC1090 Configurator software.
Smart Communication Frequency Band: 0.5 to 40 KHz within 3 dB (Hart and higher frequency protocols), only with mA direct current output.
EMC: Fully compliant with CE marking applicable requirements.
Supply: 12-24 Vdc nom (10 to 30 Vdc) reverse polarity protected, ripple within voltage limits  5 Vpp.
Current consumption @ 24 V: 90 mA with 20 mA input/output and relays energized.
Current consumption @ 12 V: 190 mA with 20 mA input/output and relays energized.
Power dissipation: 1.7 W with 24 V supply, 20 mA input/output and relays energized.
Max. power consumption: at 30 V supply voltage, input short circuit, overload condition, relays energized and PPC1090 connected, 2.9 W.
Isolation (Test Voltage): I.S. In/Outs 1.5 KV; I.S. In/Supply 1.5 KV; Analog Out/Supply 500 V; Analog Out/Alarm Outs 1.5 KV; Alarm Outs/Supply 1.5 KV; Alarm Out/Alarm Out 1.5 KV.
Input: 0/4 to 20 mA (separately powered input, voltage drop  1 V) or 4 to 20 mA (2 wire Tx current limited at  25 mA).
Integration time: 100 ms.
Resolution/Visualization: 1 µA.
Input range: 0 to +22 mA.
Transmitter line voltage:  15.0 V at 20 mA with max. 20 mVrms ripple on 0.5 to 40 KHz frequency band.
Burnout: enabled or disabled. Analog output can be programmed to detect burnout condition with downscale or highscale forcing. Alarms can be programmed to detect burnout condition.
Burnout range: low and high separated trip point value programmable between -5 to +25 mA.
Output: 0/4 to 20 mA, on max. 600  load source mode, current limited at 22 mA or 0/1 to 5 V or 0/2 to 10 V signal, limited at 11 V.
Resolution: 1 µA current output or 1 mV voltage output.
Transfer characteristic: linear or reverse.
Response time:  50 ms (10 to 90 % step change).
Output ripple:  20 mVrms on 250  communication load on 0.5 to 40 KHz band.
Frequency response: 0.5 to 40 KHz bidirectional within 3 dB (Hart and higher frequency protocols) only with mA direct current output.
Alarm:
Trip point range: within rated limits of input sensor (see input for step resolution).
ON-OFF delay time: 0 to 1000 s, 100 ms step, separate setting.
Hysteresis: 0 to 5 mA (see input for step resolution).
Output: voltage free SPST relay contact.
Contact rating: 2 A 250 Vac 500 VA, 2 A 250 Vdc 80 W (resistive load).
Performance: Ref. Conditions 24 V supply, 250  load, 23 ± 1 °C ambient temperature.
Input: Calibration and linearity accuracy:  ± 20 µA
Temperature influence:  ± 1 µA of input for a 1 °C change.
Analog: Calibration accuracy:  ± 0.1 % of full scale.
Output: Linearity error:  ± 0.05 % of full scale.
Supply voltage influence:  ± 0.05% of full scale for min to max supply change
Load influence:  ± 0.05% of full scale for 0 to 100 % load resistance change
Temperature influence:  ± 0.01 % on zero and span for a 1 °C change.
Compatibility:
CE mark compliant, conforms to Directive: 2014/34/EU ATEX, 2014/30/EU EMC, 2014/35/EU LVD, 2011/65/EU RoHS.
Environmental conditions:
Operating: temperature limits -20 to + 60 °C, relative humidity max 95 %.
Storage: temperature limits – 45 to + 80 °C.
Safety Description:
ATEX: II (1) G [Ex ia Ga] IIC, II (1) D [Ex ia Da] IIIC, I (M1) [Ex ia Ma] I, II 3G Ex nAC IIC T4 Gc
IECEx: [Ex ia Ga] IIC, [Ex ia Da] IIIC, [Ex ia Ma] I, Ex nAC IIC T4 Gc
INMETRO: [Ex ia Ga] IIC, [Ex ia Da] IIIC, [Ex ia Ma] I
UL: AIS / I, II, III / 1 / ABCDEFG, [AEx ia] IIC; C-UL: AIS / I, II, III / 1 / ABCDEFG, [Ex ia] IIC
FM: NI / I / 2 / ABCD / T4, NI / I / 2 / IIC / T4, AIS / I, II, III / 1 / ABCDEFG, AEx [ia] IIC; FM-C: NI / I / 2 / ABCD / T4, NI / I / 2 / IIC / T4, AIS / I, II, III / 1 / ABCDEFG, Ex [ia] IIC
EAC-EX: 2Ex nA nC [ia Ga] IIC T4 Gc X, [Ex ia Da] IIIC X, [Ex ia Ma] I X
UKR TR n. 898: 2ExnAnCiaIICT4 X, ExiaI X
associated electrical apparatus.
Uo/Voc = 26.3 V, Io/Isc = 91 mA, Po/Po = 597 mW at terminals 14-15.
Uo/Voc = 1.1 V, Io/Isc = 56 mA, Po/Po = 16 mW at terminals 15-16.
Ui/Vmax = 30 V, Ii/Imax = 128 mA, Ci = 1.05 nF, Li = 0 nH at terminals 15-16.
Um = 250 Vrms, -20 °C  Ta  60°C.
Approvals:
Presafe 16ATEX8917 conforms to EN60079-0, EN60079-11, EN50303.
IECEx PRE 16.0084 conforms to IEC60079-0, IEC60079-11.
IMQ 09 ATEX 013 X conforms to EN60079-0, EN60079-15.
IECEx IMQ 13.0011X conforms to IEC60079-0, IEC60079-15.
INMETRO DNV 13.0135 X conforms to ABNT NBR IEC60079-0, ABNT NBR IEC60079-11.
UL & C-UL E222308 conforms to UL913, UL 60079-0, UL60079-11, UL60079-15 ANSI/ISA 12.12.01 for UL
and CSA-C22.2 No.157-92, CSA-E60079-0, CSA-E60079-11, CSA-C22.2 No. 213 and CSA-E60079-15 for C-UL, refer to control drawing ISM0125.
FM & FM-C No. 3024643, 3029921C, conforms to Class 3600, 3610, 3611, 3810, ANSI/ISA 12.12.02, ANSI/ISA 60079-0, ANSI/ISA 60079-11,
C22.2 No.142, C22.2 No.157, C22.2 No.213, E60079-0, E60079-11, E60079-15,
C-IT.MH04.B.00306 conforms to GOST R IEC 60079-0,GOST R IEC 60079-11, GOST R IEC 60079-15.
C 16.0034 X conforms to  7113,  22782.5-78,  I 60079-15.
TÜV Declaration of Compliance No. C-IS-722238330, SIL 2 according to IEC 61508:2010 Ed.2.
TÜV Certificate No. C-IS-236198-09, SIL 3 Functional Safety certificate conforms to IEC61508:2010 Ed.2, for Management of Functional Safety.
DNV No.A-14279 and KR No.MIL20769-EL001 Certificates for maritime applications.
Mounting: T35 DIN Rail according to EN50022.
Weight: about 175 g.
Connection: by polarized plug-in disconnect screw terminal blocks to accommodate terminations up to 2.5 mm
2
.
Location: Safe Area/Non Hazardous Locations or Zone 2, Group IIC T4, Class I, Division 2, Groups A, B, C, D Temperature Code T4
and Class I, Zone 2, Group IIC, IIB, IIA T4 installation.
Protection class: IP 20. Dimensions: Width 22.5 mm, Depth 99 mm, Height 114.5 mm.
