D5093-TB - SIL3 24/220Vdc/Vac Transistor-Out Detector G.M. International ISM0541-2
4
Function Diagram
SAFE AREA, ZONE 2 GROUP IIC T4,
NON HAZARDOUS LOCATIONS, CLASS I, DIVISION 2,
GROUPS A, B, C, D T-Code T4
MODEL D5093D-TB
Out 1 (SIL 3)
10
7
8
Termination
board
connector
Out 2 (SIL 3)
9
In 1
24 - 220 Vac
In 2
24 - 220 Vdc
+
24 - 220 Vac24 - 220 Vdc
+
MODEL D5093S-TB
Out 1 (SIL 3)
7
8
Termination
board
connector
In 1
24 - 220 Vac24 - 220 Vdc
+
