EQUIPMENT’S INSTALLATION
2 - Procedures for hydraulic installation:
- Connect the hose Into the water inlet (A) and
tighten the nut.
- Connect on the inside of the connection
box the other end of the water hose, in the hose
that comes from the supply, using the tee for
connection.
The equipment’s installation shall be made by a Gnatus
authorized technician, under the penalty of missing the warranty.
1 - Procedures for installation (Pedal and electrical supply)
Pedal for activation
Pedal plug
Pedal
plug
Pedal plug
input
Power
supply
plug
Power
plug
Energy
Power supply
input
Power supply
A
39
