has been drained.
3. Remove Ref # 7A Oil Fill Cap and fill
crankcase with NON Detergent oil
(see chart) until the oil level reaches
the center mark in Ref # 11A Oil
Window.
4. Once filled, replaced Ref # 7A Oil Fill Cap.
Page 4
Specifications
Maximum Flow……………………………………………… 10 GPM
Maximum Pressure……………………………………….. 600 PSI
Maximum RPM……………………………………………. 800 RPM
Maximum Temperature……………………………………. 140°F
Inlet Port……………………………………………………………...1”
Outlet Port (Pressure)…………………………………………...⅜”
Outlet Port (Pressure)…………………………………………...½”
Outlet Port (Regulator Return Line)……………….………..¾”
Crankshaft Size……………………………………..……….…24mm
Dimensions:
Tall/Compact Mounted:………….19”H x 12”W x 15”L
Low Mounted……………………... 14”H x 12”W x 15”L
Weight………………………………………….……………….... 35lbs.
NOTE: Not following proper procedures as listed in
the detailed product manual may void all warranties
Pump Oil
Non-Detergent
SAE30 Weight
