GNC P530 - Page 8

REF # PART # DESCRIPTION
1A 42-530-01 Crank Case w/Set Pin & Plate
2 42-530-02 Piston Oil Seal
5 42-530-05 Screw
6 42-530-06 Crankshaft Oil Seal Cover
7A 42-530-07 Oil Inlet Cover Assy.
8 42-530-08 Rear Cover Packing
9 42-530-09 Crankshaft Rear Cover
10 42.530.10 Screw
11A 42-530-11 Oil Window Assy.
12A 42-530-12 Drainage Screw Assy.
13 42-530-13 Crankshaft Key
14 42-530-14 Crankshaft
15A 42-530-15 Connecting Rod Assy.
16 42-530-16 Bearing
17 42-530-17 Crankshaft Oil Seal
18 42-530-18 Crankshaft Oil Seal Cover
19A 42-530-19 Piston Assy.
26 42-530-26 Piston Pin
28* 42-530-28S Short Pump Stands (pair)
28* 42-530-28T Tall Pump Stands (pair)
29A 42-530-29 Bolt, Washer, & Lock Washer
31A 42-530-31 Pulley & Bolt
41A 42-530-41 Bolt & Lock Washer
42A 42-530-42 Double-End Screw w/Nut & Spring Washer
51A 42-530-51 Suction Chamber w/Connector
53A 42-530-53 Bolt & Washer
60A 42-530-60 Connecting Hose w/O-Ring
Page 7
