Electrical Specication Item
Model No.
GP-ISW1000-12 GP-ISW1000-24
Input
Characteristics
Voltage 12VDC 24VDC
Input Over Voltage Protection (1) 16.5 ± 0.3VDC 33 ± 0.5VDC
Input Under Voltage Protection 10.5 ± 0.3VDC 21 ± 0.5VDC
Voltage Range 10.5~16.5 VDC 21~33 VDC
No Load Current
≦1.5A @12VDC ≦0.8A @24VDC
Power Saving Mode <0.1A @12VDC <0.06A @24VDC
Output
Characteristics
Continuous Output Power 1000 VA (± 3%)
Maximum Output Power (1Min) > 1000 VA~1150 VA (100%~115%)
Surge Power (1Sec) < 1750 VA
Frequency 50 / 60 Hz ± 0.5% (Dip Switch Selectable)
Output Voltage
100 / 110 / 115 / 120 VAC (± 5%)
(Dip Switch Selectable)
E󰀩ciency Max.
92%
93%
Short-Circuit Protection 1 Sec Shutdown
Output Waveform Pure Sine Wave (THD < 5%@ Normal Load) (2)
Signal and
Control
Remote Controller Panel Unit GP-SWR-A / GP-ISW-R (optional)
LED Indicator Red / Orange / Green LED
Dry Contact Terminal By a relay
Remote Control Terminal 6-port Green terminal (for inverter ON / OFF)
Protection
Input Protection Over / Under Voltage, Reverse Polarity (Internal Fuse)
AC Output Protection Short-Circuit, Overload
Others
Over / Under Temperature Protection
(by Heat Sink Temperature +80°C/-20°C)
Environment
Operating Temp. -20 °C~40 °C (3)
Storage Temp. -30 °C~70 °C
Storage Temp. & Humidity 10 ~95% RH
Safety & EMC
Safety Standards Certied UL 458 (6th Edition)
EMC Standards Certied FCC class B
Dimension(WxHxD) 200mm X 83mm X 372mm
Weight 3.26 KG
Cooling Temperature & Load Controlled Cooling Fan
SPECIFICATIONS
