Storage instructions
Y
ard Guard
4L-8156-00
W
ARNING
!
Y
ard Guard
4L-8156-00
W
ARNING
!
9. First, make sure all hooks have been disconnected from
their corresponding D loops. Carefully lift the bottom
tube of the Yard Guard upwards and toward the net.
Gather the excess netting to the pole with one hand while
using the other to grab the top storage Strap with the
Plastic Clip on the pole pad. Simply bring the Strap
with Plastic Clip around the outside of the Yard Guard
and connect the Clip to the closest plastic D loop,
located on the back on the pole pad See Figure 20-22,
Side View and Back View. Connect the two lower straps
in the same manner. Repeat this same procedure on the
other side.
NOTE: Straps will be tight. This will help to secure
and Protect the Yard Guard.
BACK VIEW
“D” Loop
SIDE VIEW
Strap with
Plastic
Clips
Plastic
Clip
Y
ard Guard
4L-8156-00
WARNING
!
Figure 20
Figure 21
Figure 22
19
