Goalzero Sherpa 100PD User Manual

54
USING YOUR SHERPA
BUTTONS:
Press once to turn the USB ports on/off.
Turn Qi wireless charging on/off. Button light is blue when
Qi wireless charging is turned on and turns green when
connection with device is made and charging begins.
TECHNICAL SPECIFCATIONS
Charge times:
USB-C PD Source
(60W)
2.5 hrs
Wall charger
(45W)
3 hrs
USB-A (2.4A) 9 hrs
Nomad 14 14-28 hrs
Nomad 28 7-14 hrs
Battery:
Cell chemistry Li-ion NMC
Cell type 18650 by LG chem
Single Cell Equivalent
Capacity
25600mAh @ 3.7V
Lifecycles Hundreds of Cycles
Shelf-life Charge every 3-6
months
Management
system
Charging and low-
battery protection
built-in
Sherpa 100PD
Ports:
Wireless Qi (output) 5W max
USB A ports (output) 5V, up to 2.4A (12W
max), regulated,
3.4A(17W max
Combined)
USB-C PD ports
(input/output)
5V,9V,12V,15V,20V
up to 3A (60W each,
100W max), regulated
General
Chainable no
Weight 1.4 lbs (898 g)
Dimensions 7.5 x 1.0 x 3.7 in (19.0
x 2.54 x 9.4 cm)
Operating usage
temp.
32-104F (0-40C)
Certs
Warranty 12 months
Be sure to activate your warranty at
goalzero.com/warranty
NOTE: Battery level display screen will turn on when either power or Qi
wireless charging is turned on. Both Power and Qi wireless charging must be
turned off in order for the display screen to turn off
PASSTHROUGH CHARGING
It is possible to recharge other devices while the Sherpa is being charged.
Plug the Sherpa into a power source and make sure it’s still powered on, then
plug the device into the Sherpa.

Goalzero Sherpa 100PD Specifications

General

Cell Chemistry	Li-ion NMC
Weight	1.4 lbs (635 g)
Cycle Life	500 cycles to 80% capacity
USB-C Port (Input/Output)	60W max
USB-A Ports (Output)	2x USB-A (12W total output)
Wireless Charging	5W
8mm Charging Port (Input)	Yes
Operating Usage Temp	32-104 F (0-40 C)
Warranty	12 months
