13
• Do not clean the vacuum cleaner, components or accessories using
petrol or any other flammable liquid or solvents, etc.
• Clean only the outside of the vacuum cleaner.
• Use only a moist cloth and mild detergent for cleaning the vacuum
cleaner, components and accessories.
and accessories with a dry cloth.
• Do not place accessories, tools or components in a dishwasher.
Bush Roll
You should check your cleaner’s brush roll and drive belt regularly for
wear or damage. You should also clean the brush and brush ends by
removing string, hair and carpet fibres. These can wrap around the
remove any debris that has accumulated under the brush cover.
2
4 5
31
Remove
Six Screws
vacuum and unplug from electrical outlet.
Place vacuum upside down with brush roll facing upwards.
Remove the six screws as shown with a small Phillips screwdriver
(see image 1).
Lift o brush cover(see image 2).
Grasp floor brush at both ends and remove by lifting out(see image 3).
Clean string, hair and other debris from floor brush, motor pulley, and
drive belt(see image 4).
Check air passageway for obstructions. Remove debris from this area.
When finished cleaning, reposition floor brush and drive belt. Turn
floor brush by hand several times in the direction of the motor pulley.
If properly installed, the drive belt will align itself on floor brush. Then
replace the brush cover and re-install the six screws（see image 5)
