Goblin SPEED - Page 28

......
x4
Plastic Ball Link
(H0066-S)
Threaded Rod M2.5x40mm
(HC242-S)
A
DETAIL A
SCALE 1 : 1.7
Socket Head Cap Screw
M3x12mm
(HC062-S)
Finishing Washer M3
(H0007-S)
3mm
3mm
Approx 752mm
12mm12mm
Socket Head Cap Screw M3x12mm
......
x4
Finishing Washer M3
Finishing Washer M3
(H0007-S)
Socket Head Cap Screw
M3x12mm
(HC062-S)
Tail Boom
Assembly
Plastic Ball Link
(H0066-S)
Carbon Rod
4x 2.5x702mm
(HC239-S)
Threaded Rod M2.5x40mm
(HC242-S)
Note:
Copyright © 2013 - SAB Heli Division - All rights reserved
Page 26
Chapter 12, Tail
