Goblin SPEED - Page 42

- 1 x Bearing 3 Support.
- 1 x Motor Support.
- 1 x Flanged Bearing
6x 13x5mm.
- 2 x Socket Head Cap Screws
M3x8mm.
- 2 x Set Screws M5x20mm.
- 2 x Washers
5.3x 15x1mm.
- 2 x Metric Hex Nylon Nuts M5H4.8.
- 2 x Finishing Washers M3.
- 2 x Socket Head Cap Screws
M3x10mm.
- 2 x Metric Hex Nylon Nut M3 H4.
- 2 x Springs de 5.8/ df0.5 / LL9.
- 2 x Springs de 3/ df0.5 / LL12.
Motor Mount Cooling
[H0316-S]
- 1 x 19T Drive Pinion.
- 1 x Socket Head Cap Screw
Shouldered M3x22mm.
- 1 x Metric Hex Nylon Nut
M3H4.
19T Drive Pinion
[H0156-S]
- 1 x Aluminum Front Tail Pulley.
- 1 x Socket Head Cap M2.5x19mm.
- 1 x Metric Hex Nylon Nuts M2,5H3,5.
Aluminum Front Tail Pulley
[H0172-S]
- 1 x Column Belt Tensioner.
- 1 x Tail Belt Idler.
- 1 x Belt Tensioner Arm.
- 2 x Flanged Bearings
3x 7x3mm.
- 2 x Flanged Bearings
5x 9x3mm.
- 1 x Socket Head Cap Screw M3x50mm.
- 1 x Washer
3x 4x0.5mm.
- 1 x Socket Head Cap Screw M3x12mm.
- 2 x Washers
3.2x 6x0.5mm.
- 1 x Button Head Cap Screw M3x4mm.
- 1 x Spring De8/df0.5/LL8.
Belt Tensioner Support
[H0174-S]
- 1 x 18T Pulley.
- 1 x Set Screws M4x4mm.
- 1 x 19T Pulley.
- 1 x Set Screws M4x4mm.
19T Pulley
[H0175-19-S]
18T Pulley
[H0175-18-S]
- 1 x 23T Pulley.
- 1 x Set Screws M4x4mm.
23T Pulley
[H0175-23-S]
- 1 x 22T Pulley.
- 1 x Set Screws M4x4mm.
22T Pulley
[H0175-22-S]
- 1 x 21T Pulley.
- 1 x Set Screws M4x4mm.
21T Pulley
[H0175-21-S]
20T Pulley
[H0175-20-S]
- 1 x 20T Pulley.
- 1 x Set Screws M4x4mm.
- 1 x 24T Pulley.
- 1 x Set Screws M4x4mm.
- 1 x Steel Tail Shaft Assembly.
- 1 x Tail Oring Damperner.
Steel Tail Shaft
[H0325-S]
- 2 x Quick Release Canopy Assembly.
- 2 x Flat Head Socket Cap M3x8mm.
- 2 x Canopy Grommets.
Quick Release Canopy Mount
[H0319-S]
Plastic Tail Linkage
[H0261-S]
- 1 x Plastic Tail Linkage.
- 1 x Grip Link Bushing.
- 1 x Socket Head Cap Screws M2x6mm.
- 2 x Blade Grip Arm.
- 2 x Socket Head Cap
Screw M4x10mm.
- 2 x Uniball M3x4 Ø5 H3.5.
Blade Grip Arm
[H0183-S]
Blade Grip
[H0182-S]
- 2 x Blade Grip.
- 2 x Thrust Bearing
10x 18x5.5mm.
- 4 x Bearing
10x 19x5mm.
- 2 x Washer
10x 16x1mm.
- 2 x Button Head Socket Cap M4x10mm.
Aluminum Tail Blade Grip
[H0327-S]
- 2 x Aluminum Tail Blade Grip.
- 4 x Bearing Ø5xØ10x4mm.
- 2 x Thrust bearing Ø5xØ10x4mm.
- 2 x Button Head Cap M4x8mm.
- 2 x Socket Head Cap M2x6mm.
- 2 x Washer Ø5xØ8.9x0,75mm.
- 2 x Washer Ø7.5xØ10x0,5mm.
24T Pulley
[H0175-24-S]
- 1 x Aluminum Double Bearing
One Way Pulley.
- 3 x Shims
10x 16x0,2mm.
- 1 x One Way Brass Bushing.
Double Bearing One Way Pulley
[H0171-S]
68T Main Gear
[H0320-S]
- 1 x 68T Main Gear .
- 1 x Socket Head Cap ScrewM4x25mm.
- 1 x Metric Hex Nylon Nut M4 H5.
- 1 x 19T Drive Pinion.
- 1 x Socket Head Cap Screw
Shouldered M3x22mm.
- 1 x Metric Hex Nylon Nut M3H4.
