Godex EZ-1105P series User Manual

EZ300 Series
3
Open The Printer Cover
Open The Printing Mechanism
ADJUSTMENT SCREW ( LEFT )
Screw for adjusting the print head pressure
LABEL SUPPLY MODULE
- LABEL SUPPLY HUB
- LABEL GUIDE PLATES ( SET of 2 )
ADJUSTMENT SCREW ( RIGHT )
Screw for adjusting the print head pressure
RIBBON MODULE
- RIBBON FEED MECHANISM
- RIBBON HUB
- EMPTY RIBBON CORE
LABEL GUIDE ( LEFT )
ADJUSTMENT SCREW
Screw for adjusting
the print line
LABEL GUIDE ( RIGHT )
PLATEN
LABEL SENSOR
Movable
RIBBON SUPPLY HUB
PRINTING MECHANISM
RELEASE CATCH ( RIGHT )
RELEASE CATCH ( LEFT )
