To avoid overheating or deteriorating the flash head, the over-temperature protection
function will be activated automatically after 10 continuous high-speed flashes and the
recycle time becomes 10s longer.
8. LED Light Control
When the LED light is turned on, the icon is shown on the LCD display.
Press the LED Light Control Button (14) to control LED light: Off→30%→70%→100%→
Off……
Protection Function
When the over-temperature protection is started, is shown on the LCD display.
To avoid overheating and deteriorating the flash head, do not fire more than 40
continuous flashes in fast succession at 1/1 full power. After 40 continuous flashes, allow a
rest time of at least 10 minutes.
If you fire more than 40 continuous flashes and then fire more flashes in short intervals,
the inner over-temperature protection function may be activated and make the recycling
time about 10 to 15 seconds. If this occurs, allow a rest time of about 10 minutes, and the
flash unit will then return to normal.
Over-Temperature Protection
Number of flashes that will activate over-temperature protection:
Power Output Level
1/1
1/2+0.7
1/2+0.3
1/2
1/4(+0.3/+0.7)
1/8(+0.3/+0.7)
1/16(+0.3/+0.7)
1/32(+0.3/+0.7)
1/64(+0.3/+0.7)
1/128(+0.3/+0.7)
Number of Flashes (Approx.)
40
60
80
100
200
300
400
400
500
500
Power Output Level
1/1
1/2
1/4
1/8
1/16
1/32
Number of Flashes (Approx.)
10
15
20
30
40
50
Number of flashes that will activate over-temperature protection in high-speed sync
triggering mode:
To enter mode, press both Mode Selection Button (16) and LED Light Control Button(14).
Press Mode Selection Button (16) again to exit mode.
7. Hi-Speed Sync Triggering
hi-speed sync trigger, e.g., Godox Cells II transceiver.
In hi-speed sync triggering mode, you can use a hi-speed sync trigger to have your flash
unit synchronize with all shutter speeds of cameras(max. 1/8000 second, up to your
camera). This is convenient when you want to use aperture- priority for fill-flash portraits.
Note:
camera hotshoe.
Hi-speed sync triggering mode is effective only when the flash unit is used together with
Hi-speed sync triggering mode is not available when the flash unit is mounted onto the
Step
100%
70%
30%
Time of Auto off
5 min.
10 min.
15 min.
9. Buzz Function
The buzz function can be controlled by pressing BUZZ Button (15).
10. Wireless Control Function
When the buzzer is turned on, is shown on the LCD display.
The flash unit is built in with a Wireless Control Port (9) so that you can wirelessly control
the on-and-off of your flash, modeling lamp and buzzer, as well as adjust the flash output
camera and on-flash transceiver). Insert its receive end into the Wireless Control Port (9)
To control the flash wirelessly, you need a Godox FT series remote control set (on-
hotshoe-mounted transceiver and receive ends will be wirelessly communicated to the
level, etc.
flash. Then you can press the camera shutter-release button to trigger the flash.
When the flash unit receives wireless signals, is shown on the LCD display.
11. Sync Triggering
Insert one end of a PC sync cable into the PC Sync Socket (11) of the flash unit and the
other end into the PC Sync Socket on the camera. The flash unit will fire when the camera’s
shutter-release button is pressed.
on the flash and insert the transmit end into the camera hot shoe. Settings made on the
The Sync Cord Jack (10) is a Φ3.5mm plug. Insert a trigger plug here and the flash will be
fired synchronously with the camera shutter.
For full instructions on the use of FT series remote control, see its user manual.
12. PC Sync Triggering
