Code
n(Mode)
n+1
n+2
CCT
FX
Note
0-51 52-255
Operation
Mode
DMX*(100/255)
Integer
0-100% Brightness
DMX*(total light
effects/255)
For example: total light
effects 8，DMX=160,
light effects
No.=160*8/255=5
3. DMX Control Mode
In main interface, short press DMX button to
enter the DMX interface and the icon will be
blinking. Then, turn the select dial to set the DMX
channel from 1 to 512. Adjustment in 10 values
quickly or 1 value normally.
DMX Parameters:
DMX*(100/255)
Integer
0-100% Brightness
- 19 - - 20 -
* Product design and specifications are subject to change without notice.
Technical Data
Maintenance
This product, except consumables e.g. battery, power cable and connect cable, is
supported with a one-year warranty.
Avoid sudden impacts and the product should be dedusted regularly.
Maintenance of the flash must be performed by our authorized maintenance
department which can provide original accessories.
Unauthorized service will void the warranty.
If the product had failures or was wetted, do not use it until it is repaired by
professionals.
Changes made to the specifications or designs may not be reflected in this
manual.
Silent LED Video Light
Power Supply
Output Power
Color Temperature
100% Illuminance(LUX)
(1m,darkroom) (≈)
CRI
TLCI
Brightness Range
Channel(CH)
Group (GR)
Working Environment Temperature
Control Method
2.4G Wireless Transmission Distance (≈)
Dimension (≈)
New weight(≈)
UL60
AC Power Supply 100~240V 50/60HZ 0.9A
V-port battery Standard voltage: 14.8V (optional)
60W
5600K±300K
31000
≥96
≥97
0~100%
32
16
-10~40°C
Smartphone APP/2.4G wireless
remote control/ DMX control
50m
Light body: 225*119*263mm
(included U-type bracket and sleeve)
Controller: 268*113*64mm
Light body: 2.38kg
Controller: 0.94kg
Short press SET or DMX button to back to the
main interface after finished all settings.
