Article No. 28 100-
Version 12.2007
Page 7 of 12
Example 3 Well, 7.50 m maximum water level from ground of the well
(fill level 4.20 m), relay switching function is desired.
Probe TDS-6029 (measuring range 0 – 1000 mbar), indication in m water column.
Step
Entries
1. Probe 1000 mbar 1000mbar
2. Medium: water H2O
3. Tank shape (well shape): linear Linear
4. Max. value 7500 (indicated in m) 7,500L (set with +/- keys)
5. Inner tank height 7.50m 7,500mm (set with +/- keys)
6. Relay1 – ON at <05% - OFF at >10% active ➜ On: 05% → Off:10%
7. Relay2 – no function
8. Exit ➜ press PLUS key to go to
12. Unit – indicated unit: m Unit: m
13. Rounding: auto auto (just confirm with ENTER)
14. Exit ➜ press ENTER to see the indication ➜ e.g. 4.20m
Notes on programming
Menu item
Setting
Description
0.Exit
Back to display mode
1.Probe
100mbar
150mbar
250mbar
500mbar
1000mbar
2000mbar
3000mbar
5000mbar
Set mbar
Cal mode
Tank height heating oil up to 1.2 m – water up to 1 m
Tank height heating oil up to 1.8 m – water up to 1.5 m
Standard probe - tank height heating oil up to 3 m – water up to 2.5 m
Tank height heating oil up to 6 m – water up to 5 m
Tank height heating oil up to 12 m – water up to 10 m
Tank height heating oil up to 24 m – water up to 20 m
Tank height heating oil up to 36 m – water up to 30 m
Tank height heating oil up to 60 m – water up to 50 m
Entry of a specific probe with different measuring range
Is only indicated if item 10. Set h or 11. Set V has been activated
2.Fluid
Medium
Heat.oil
H2O
Diesel
BioD
RME,FAME
Rapsoil
Palmoil
Motoroil
AdBlue
Normal-B
Super-B
Set kg/m3
Cal mode
845 kg/m3 - default setting
999
830
880
880 (rapeseed, methyl ester, fatty acid methyl ester)
915
910
865
1.090
743
750
Entry of a specific density value
Is only indicated if item 10. Set h or 11. Set V has been activated
If the density of the stored medium is unknown, the reference height can be entered in menu item
10. Set h. To this end, determine the current fill level in mm, deduct 10 mm
from it and enter the
resulting value - click YES to confirm the entry.
Should the current fill level be smaller 75%, we urgently recommend to adjust the value after the
next refueling to achieve a good measuring accuracy.
3. tank
tank
shape
Linear
Default setting
linear tank, rectangular tanks, vertical
cylinders, basement-welded steel tanks.
