Article No. 28 100-
Version 12.2007
Page 6 of 12
On: +0°C ➜ ON: set with + / - ➜ Enter
Off:+0°C ➜ OFF: set with + / - ➜ Enter
Deactivate the relay or beeper via deactive
or input of 0% or 0°C (for On and Off).
On ___°C
Off ___°C
7. Relay2
See 6. Relay 1 for the data for Relay 2
8. Exit (quit)
Press Enter to return to display mode
After performing entry steps 1 - 7, the programming process is completed. After confirmation of
step 8 “Exit“, the device automatically returns to standard display mode; the current tank content
is shown in the display.
Special functions are available under entry steps 9 to 13 (see page 9).
After the end of setup, do not forget to re-screw the housing cover!
Examples for programming
Example 1 Basement tank for 6000 liters heating oil, liter indication, linear steel tank
Inner height 165 cm, (fill level 125 cm)
Standard probe TDS-6023 0 – 250 mbar
Step
Entries/selection
1. Probe 250 mbar 250mbar
2. Medium: heating oil Heat.oil
3. Tank shape: linear Linear
4. Tank volume: 6000 liters 6000L (set with +/- keys)
5. Inner tank height: 165 cm 1,650mm (set with +/- keys)
6. Relay 1 – no function deactive
7. Relay 2 – no function deactive
8. Exit ➜ press ENTER to see the indication ➜ e.g. 4550L
Example 2 Buried tank, cylindrical, horizontal, for 100,600 liters Diesel oil
Inner height 2.886 m, (fill level 54 cm)
Standard probe TDS-6023 0 – 250 mbar
Step
Entries
1. Probe 250 mbar 250mbar
2. Medium: Diesel Diesel
3. Tank shape cyl. horizontal >50m
3
Cyl.>50m3
4. Tank volume: 100,600 liters 100,600L (exact value from volume table
)
5. Inner tank height: 288 cm 2,886mm (exact value from volume table
)
6. Relay 1 – no function deactive
7. Relay 2 - no function deactive
8. Exit ➜ press ENTER to see the indication ➜ e.g. 12800L
Tank with inner casing
For tanks with inner casing (e.g. cyl. horizontal or basement-welded tanks), the entries for inner
height and volume should be adjusted.
Examples:
➜ Wall thickness of inner casing 0.5 cm ➜ reduce value for inner height by approx. 1 cm, reduce
volume for 10 m³ by 1.3%, for 20 m³ by 1%, for 50 m³ by 0.8% and for 100 m³ by 0.7%.
➜ Wall thickness of inner casing 2 cm ➜ reduce value for inner height by approx. 4 cm, reduce
volume for 10 m³ by 5%, for 20 m³ by 4%, for 50 m³ by 3% and for 100 m³ by 2.5%.
