LM5000C LIFT FRAME PARTS LIST
Part Number Description
Qty. Per
Unit
BB5003 Washer, 380 x 750 x 062 Nylon
2
BB5512 Pin, 3/8 x 1 5/8 Zinc Clevis
1
BB5514 Pin, Hitch
11
BB5515 Cap, 1" Square End Chair
8
BB5518 Tywrap, 8" Black 2
BB5530 Leg Leveler 5/16 X 1
4
BB5531 Pin, 3/8 x 2 1/2 Zinc Clevis
1
BB5535 Washer, 750 x 394 x 125 Nylon
6
BB5549 Washer, 400 x 750 x 312 Nylon
2
BB5566 Pin, 3/8 x 3 1/2 Zinc Clevis
4
BB5567 Pin, 3/8 x 2 5/8 Zinc Clevis
1
BB5579 Pin, 3/8 x 2 7/8 Zinc Clevis
4
GM1500-LM DC INLINE MOTOR
1
LM5000C 5000C LIFT FRAME
1
LM-RS5100 RECLINE STRAP 5100 / 6111 SERIES LIFT FRAME
2
ZK1200-HC Hand Wand, 2 Button LED with Walnut Burl Grain
1
RECLINE BAR FOR 5000C LIFT FRAME
RB4000-CB RECLINE BAR CAPRI
1
RECLINE MECHANISMS FOR 5100 LIFT FRAME
RM8300L 2 WAY MECHANISM LEFT SIDE
1
RM8300R 2 WAY MECHANISM RIGHT SIDE
1
LEFT AND RIGHT IS DETERMINED BY SITTING IN CHAIR
TRANSFORMER FOR 5100 LIFT FRAME
GM1501-A Motor Chair Transformer
1
GM1501-APUS
Transformer Cord
1
CALL TECHNICAL SERVICE FOR FABRIC, FOAM, SPRING AND WOOD PART NUMBERS AND PRICING
Note: Refer to “Models Quick Reference” chart for correct hand control by model.
