Golden BUZZ ABOUT GP164 - Adjusting Footrest Angle; Adjusting Joystick Bracket Length

19
VI. COMFORT SETTINGS
Footrest Angle Adjustment
1. Fold the footrest upward for easy access to the angle adjustment bolt. See figure 11.
2. Use an 6mm Allen wrench to turn the adjustment bolt. Turning the adjustment bolt
counter-clockwise will decrease the footrest angle. Turning the adjustment bolt
clockwise will increase the footrest angle. Turn until desired angle is reached.
Joystick Bracket Length Adjustment
1. Loosen the adjustment screw. See figure 12.
2. Slide the joystick holder in or out to the desired position.
3. Tighten the adjustment screw.
Figure 11
Figure 12
Angle Adjustment
Bolt (6mm Allen)
Adjustment Screw
