Compass HD Owner’s Manual – Models GP620 SS, GP620 CC Revised 10/27/14
10
SPECIFICATIONS
Model GP620 SS GP620 CC
Medicare Code K0824 K0825
Maximum Incline 6 degrees 6 degrees
Weight Capacity 450 lbs. 450lbs.
Maximum Speed 4 mph 4 mph
Operating Range
1
12 miles 12 miles
Ground Clearance 3.5” 3.5”
Turning Radius 20 " 20 "
Type Batteries 2-NF22 2-NF22
Colors Red, Blue Red, Blue
Charger Off Board Off Board
Controller
Dynamic Shark
75 Amp
Remote
Dynamic Shark
75 Amp
Remote
Dimensions:
Length 40" 40"
Width (outside of tires) 25" 25"
Height (ground to top of back of seat) 38.25” – 42.75” 38.25” – 42.75”
Height (ground to top of back of headrest) 47.25” – 53.75” 47.25” – 53.75”
Ground to Top of Seat 19.75” – 22.25” 21.25” – 24.25”
Number of Seat Height Positions 5 5
Size of Increments 0.5” 0.5”
Weight of Unit: (assembled)
223 lbs. 226 lbs.
Base 101 lbs 101 lbs
Seat Arms 14 lbs 14 lbs
Seat (18 X 18 Solid Pan Seat) 34 lbs
Seat (18 X 18 Captain's Chair Seat) 37 lbs
Batteries NF22 - 37 lbs NF22 - 37 lbs
Tires:
Flat Free Flat Free
Center Drive Wheels (2) 10” 10”
Casters (4) 6” 6”
Standard Seat:
Captain’s Van/Pan Captain’s Highback
Back Height-no headrest 23” 21”
Back Height with headrest 30.5” – 34.5” 28.5” – 32.5”
Width x Depth 20” x 20” 20” x 20”, 22” x 20”, 24” x 20”
Color Coffee/Sand, Charcoal/Gray Coffee/Sand, Charcoal/Gray
Electric Rise Seat (Option) N/A N/A
Footrest:
Height adjustable 3" - 7” 3" - 7”
Angle adjustable 0 – 35 degrees 0 – 35 degrees
Warranty:
Frame 5 Years 5 Years
Drive Train 13 months 13 months
Electronics
2
13 months 13 months
1. Battery range will vary due to rider weight, drive surface, and terrain.
2.Electronicswarrantyexcludesbatteries.
Literatureiscurrentatthetimeofprinting.GoldenTechnologiesreservestherighttomakechangestotheproduct
orliteratureatanytime.
