GOLDONI Aster 35 - Dimensions and Weights

72
Dimensions and weights
35 40 45
A Min-max length
mm
2485 -2560 2575 - 2650
N/M Min-max width
mm
1060 -1600 1060 - 1600
F Min-max height to chassis
mm
1825 -1900 1825 - 1900
Q Min-max height to cab
mm
2140 - 2230 2140 - 2230
K Min-max height to seat
mm
975 - 1050 975 - 1050
H Min-max ground clearance
mm
250 - 330 250 - 330
C Wheelbase
mm
1620 1685
P Min-max front track
mm
900 - 1200 900 - 1200
L Min-max rear track
mm
860 - 1270 860 - 1270
Minimum turning radius with brakes
m
2.8 3
Weight with safety frame
kg
1380 1450
Weight with cab
kg
1480 1550
Front ballast
kg
15 x 5
