2
SAFETY PRECAUTIONS
- Video door entry system with simplified installation (non-polarised 2 wire bus).
- AUp to 4 access panels (DP-GB2 distributor required for more than one access panel) per installation.
- Up to 2 apartments (N5110 Vesta2 1-apartment kit and N5220 Vesta2 2-apartment kit) per installation.
- Maximum 23 Vesta2 monitors per installation.
- Maximum 16 Vesta2 monitors in one apartment.
- Maximum 4 Vesta2 monitors in parallel (without distributors) per installation.
- Call confirmation tone.
- Visual indications on the door panel for people with impaired hearing (indicating call process,
communication, door open and channel busy).
- isAudible indications on the door panel for people with impaired vision (indicating call in progress,
resident unavailable is ommunication is finished system is busy, try later, door open, c and ).
- Always disconnect the power supply before making modifications to the device.
- installationThe and handling of these devices must be carried out by .authorised personnel
- The wiring must run at least .40 cm away from any other wiring
- In the power supply unit:
wDo not overtighten the screws on the connection block.
wInstall the power supply in a dry and protected place free risk of water .without drip or projections
wAvoid locations that are humid, dusty or near heat sources.
wDo not block ventilation holes of the equipments so that air can circulate freely.
wTo avoid damage, the power supply firmlyhas to be fixed.
wTo prevent electric shock, do not remove the cover or handle the wiring connected to the
terminals.
CHARACTERISTICS
SYSTEM OPERATION
*
( )
*
( )
For more information, see the “TKIT632 VESTA2 User Manual (code 50121919)”.
https://doc.golmar.es/search/manual/50121919
3
DOOR PANEL INSTALLATION
1650
1850
1450
Positioning the embedding box:
Make a hole in the wall to position the top of the door panel at a height of 1.65m.
Hole dimensions NCEV-90CS embedding box, 99(W) x 135,5(H) x 40(D) mm.
:
*
( )
For more information, see the “TKIT632 VESTA2 User Manual (code 50121919)”.
https://doc.golmar.es/search/manual/50121919
*
( )
Description of the door panel LED lights (for low light conditions).
Description of the visual indications on the door panel.
Description of the vocal synthesis (audible indications on the door panel).
Adjusting the vocal synthesis volume.
Adjusting the door panel communication volume.
If after starting the system the door panel audio volume seems inadequate, follow these steps:
- Call an apartment.
-The call is received in the apartment. Establish communication by pressing the push
button on the monitor.
- Next, press the push button used to call the apartment for 3 seconds until a number of
con#rmation tones are heard and the door panel communication LED starts to blink.
- Each press on the same call button will increase the door panel volume and LED blink speed.
.
There are 5 volume settings and the blink speed of LED will increase for each. Slow to fast
blink - low to high volume. After reaching “setting 5”, that is, maximum blink speed and volume,
the next setting is “setting 1”, that is, minimum blink speed and volume (carousel mode).
- To save the volume setting keep the push button used to call the apartment pressed until a
con#rmation tones are heard and the door panel communication LED turns off.
LOCK RELEASE INSTALLATION
*
( )
*
( )
*
( )
*
( )
*
( )
- To make a call, the visitor must press the button of the apartment; an audible sound indicates that
the call is being made and LED will turn on. If vocal synthesis is , a “Call is in progress”activated
will indicate .a call is being made. At this moment the apartment's monitor(s) receives the call
During the call the visitor can correct his call by pressing a push button corresponding to a
different apartment, in which case the original call is cancelled.
- In systems with several access doors, the other door panel(s) will be automatically disconnected.
If another visitor tries to call, a telephone tones will be heard to indicate that the system is busy
and LED will illuminate If vocal synthesis is activated, the message “System is busy, try later”.
will be indicated on the door panel.
- The call lasts for 40 seconds. The image appears on the monitor (with code 0 “apartment 1” or
monitor 16 if the call is in “apartment 2”) when receiving the call without the visitor knowing.
If the call is not answered within 40 seconds, LED will turn off and the channel will be freed.
- To establish communication, press button on any monitor in the apartment. Door panel
LED will turn on. If the vocal synthesis is the message “you can speak now” will beactivated
heard confirming the communication is activated.
- .Communication will last for one and a half minutes or until button is pressed again When
communication has finished, LEDs and will turn off and the channel will be freed If vocal.
synthesis is activated, a “Communication is finished” message will indicate that the call is over.
- To open the door, press button during the call or communication processes: one press will
activate the lock release for five seconds and LED will also turn on for five seconds If vocal.
synthesis is activated, a “Door is open” message will be indicated on the door panel.
- For a description of the functioning and setup of the monitor, see the monitor’s user manual.
3.5 x 25
DIN-7972
If the lock release is to be fitted to a metal door, use a Ø3.5mm drill bit and
thread the hole made. For wooden doors, use a Ø3mm drill bit.
Lock release installation instructions:
M 4 x 8
DIN-963
IMPORTANT: The lock release must be Golmar 12V AC or DC. With the
AC lock release (TF-104 power supply required), fit the varistor supplied with
the kit directly to the lock release terminals to ensure the device functions
correctly.
*
( )
