Page 4

Tricycle Components

1 Frame 1a Front forks

2 Rear fork assembly 2a Rear carry basket

3 Handlebar 3a Brake lever 3b Brake calliper 3c Handle bar stem 3d Handlebar grips

4 Drive train 4a Chainwheel 4b chain 4c Rear sprocket

5 Saddle 5a Seat post 5b seat clamp 5c q/r alloy lever

6 Front wheel 6a 20 x 1.75 alloy rim 6b 36 hole steel hub 6c stainless steel spokes

7 Rear wheel 7a 20 x 1.75 alloy rim 7b Sealed 36 hole hub 7c stainless steel spokes

8 Tyres & tubes 8a 20 x 1.75 tyres 8b 20 x 1.75 A.V. tubes 8c 20 x 1.75 rim tape

9 Pedals with reflectors

10 Safety 10a Chain cover 10b Mudguards 10c Warning device (bell)

11 Reflectors 11a Front reflector 11b Wheel reflector(3) 11c Mudguard reflector(2)

12 Other 12a Front brake

cable

12b V brake parts 12c Mudguard parts 12d Frame Parts

13 Owners Manual with Warranty details

Additional parts for external gear model

14 Rear band brake assembly 14a Brake lever 14b Brake cable and fittings

15 Rear Gear lever 15a gear cable 15b gear lever fittings

POWER ASSISTED TRICYCLES

Any power assisted conversion must be well designed with the units, components and control mechanisms

customised to suit the design of this tricycle.

Your dealer will have the latest information on the most appropriate power assisted front wheel option.

Front forks on all Gomier tricycles have an opening of 100mm and if any wheel other than the original wheel

supplied with the tricycle is to be installed then the cone distance of the front hub in this wheel must not exceed

100mm.

Front wheels with a cone distance greater than 100mm will void the warranty.

Electric Vehicles Pty Ltd electric powered front wheel kit (PowerPed EVO) is approved for use on all

Gomier tricycles. www.evehicle.com.au

Read carefully all manufacturers’ instructions for the installation of power assisted front wheel

Any modifications to the original design of the frame and fork will void the warranty.
