49216
Goobay® by Wentronic GmbH
Pillmannstraße 12 | 38112 Braunschweig | Germany
REV2022-10-11
V1.0aw
Fig. 1.
Fig. 2.
Fig. 3.
Technische gegevens / Tekniske data / Tekniska data / Technická data / Dane techniczne
Item number 49216
Connections
IN: Micro USB 2.0 socket
OUT: 2x USB-A 2.0 socket
Input 5 V
, max. 2 A, 10 W
Output 5 V
, max. 2 A, 10 W
Solar charging current 200 mA
Charging cycles ≥ 500
Battery Lithium-Polymer (Li-Pol) 3.7 V
, 8000 mAh, 29.6 Wh
Dimensions | Weight 140 x 77 x 22 mm | 246 g
Protection against
deep discharge, overcharge voltage,
overdischarge voltage, overcurrent
Operating conditions -10°C ~ +60°C | 25% ~ 70% RH
Storage conditions -10°C ~ +50°C | 10% ~ 80% RH
Charging cable
Connections Micro-USB plug, USB-A plug
Cable length 50 cm
Gebruikte symbolen / Brugte symboler / Använda symboler / Použité symboly /
Stosowane symbole
Direct current IEC 60417- 5031
Recycling ISO 7001 - PI PF 066
Avoid contact with heat/re -
- 11 -
Subject to change without notice.
NL | DA | SV | CS | PL
