Goobay MES MULTI DS-568F User Manual

11
12 Specications:
Operation Voltage 9V DC (9V block battery 6F22)
Display 21mm, LCD displays max. 1999
Ranges 20mF - 200pF
Dimensions 189 x 91 x 32 mm
Weight 300g including battery
Operation Condition 0°C ~ 40°C (32°F ~ 104°F)
Relative Humidity < 75%
Storage Condition -10°C ~ 50°C (14°F ~ 122°F)
Relative Humidity < 85%
housing Kunststoff
Fuse 250V 0.5A quick acting
11 Troubleshooting:
Problem Help
display only shows
“000“
- Select a lower range.
display shows “1“ - Select a higher range.
incorrect measure-
mens
- Adjust the Zeroing switch for calibration.
device shows no
function
- Change the battery or the fuse like described in chapter 8.
other questions - Contact your dealer.
13 Table of measuring value:
Accuracy: +/- (% Reading + number of digits) within one year
Temperature: 23°C+/-5°C, RH <75%
Temperature Coefcient: 0.1%/1°C for ranges 200pF, 2nF, 20nF, 200nF
0.2%/1°C for ranges 2µF, 20µF 200µF 2000µF, 20mF, 200mF
