Goobay SAT MOD HF-3000 User Manual

English
Applications
Audio/VideomodulatorforconnectiontoaTVsetorforfeedingintoacommunal
installation.Forexample,aCCDcamera,aVCR,aDVDplayerorsimilardeviceis
connectedtotheinput.Thisallowsyoutouseacameratomonitorachild’sbedroom,
anentranceareaoranyothersensitivearea.Theoutputissettoanotherwise
unoccupiedUHFchannel(channel21–69)viasimpleprogramming.Thesignalis
subsequentlyfedintoabuildingdistributionsystem(cableTV,SATorterrestrial)and
isthusavailabletoalltheconnectedparties.
Itcanalsobefedintotheterrestrialinputofamulti-switchinordertosupplyallmulti-
switchoutputsinaSAT-IFdistributionsystem.
Scope of Delivery:
•consistsof:1modulator,1plug-inpowersupplyunitand1coaxialconnectioncable
Features:
• SCARTinput
• SCARToutput(loopthrough)
• 1RCAinput(2xCinchaudio,1xCinchvideo)
• Aerialinput
• Aerialoutput(TV)
• Powersupplyunitinput9~12VDC(viaincludedadapter)
• ON/OFFswitch
• Channelssettablevia(Up/Downbuttons)
• LEDchanneldisplay

Goobay SAT MOD HF-3000 Specifications

General

Brand	Goobay
Model	SAT MOD HF-3000
Category	Modulator
Language	English
