Goobay SAT MOD HF-3000 User Manual

English
Technical Data:
RF- part
Inputfrequency 45~862MHz
Input IEC,coaxialsocket,75Ohm
Outputchannels CH2-12;S01-S03;S1-S41;CH21-69
Outputfrequency 45~862MHz
Output IEC,coaxialplug,75Ohm
Audio/Video part
Input
1xvideoRCA,2xaudioRCA,
1xScart
Output Scart(LoopThrough)
Videoinputimpedance 75~1.3kOhm
VideoS/N 40 dB min
Audioinputimpedance 10kOhm
Voltagesupply 9~12VDC
Accessories
VoltageadapterAC/DC 230VAC(9~12VDC@200mA)
Connectioncable coaxial–connectioncable(plug/socket)
DVD Player
Plasma
VCR/TV
DVD Player
DVD
settopbox
VCR
(1)
(4)
(5)
(3)
(2)

Goobay SAT MOD HF-3000 Specifications

General

Brand	Goobay
Model	SAT MOD HF-3000
Category	Modulator
Language	English
