Goodman CPG SERIES - Standard Horizontal

30
APPENDIX A BLOWER PERFORMANCE TABLES
BELT DRIVE
STANDARD HORIZONTAL
CPG036 STANDARD BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2
1524 0.32 1340 0.25
0.4
16280.4113960.3211710.24 900 0.16
0.6
1541 0.43 1284 0.32 1024 0.23 714 0.14
0.8
1444 0.45 1193 0.33 936 0.24
1.0
1111 0.34 806 0.23
1.2
744 0.22
CPG048 STANDARD BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2
1800 0.47 1556 0.35
0.4
20020.6517080.4914380.3611670.22
0.6
1910 0.67 1612 0.50 1330 0.37 1030 0.23
0.8
1813 0.69 1571 0.54 1222 0.36 989 0.25
1.0
1478 0.56 1142 0.32
1.2
1107 0.41
CPG060 STANDARD BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2
24600.9622510.8020730.6518620.51
0.4
24081.0022060.8419820.6818080.5515720.41
0.6
2402 1.08 2173 0.89 1943 0.72 1701 0.55 1511 0.43
0.8
2153 0.95 1917 0.77 1667 0.59
1.0
1888 0.82 1634 0.63
1.2
1601 0.67
CPG072 STANDARD BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.2
2749 1.18 2573 0.96 2402 0.79
0.4
26801.2225441.0623460.8421640.68
0.6
26551.3124981.1023060.9220940.7218900.57
0.8
2703 1.47 2486 1.20 2263 0.97 2076 0.81
1.0
2515 1.34 2272 1.07 2002 0.83
1.2
2253 1.16 2028 0.93
NOTE
ESP, In
H
2
O
TURNS OPEN
012345
Tables represent dry coil without filter, to compensate for filter add 0.08" to measured E.S.P.
SCFM correction for wet coil = 4 %.
ESP, In
H
2
O
TURNS OPEN
012345
ESP, In
H
2
O
TURNS OPEN
012345
ESP, In
H
2
O
TURNS OPEN
012345
