APPENDIX A BLOWER PERFORMANCE TABLES
BELT DRIVE - HIGH STATIC HORIZONTAL
CPG036 HIGH STATIC BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6
1568 0.45 1266 0.32
0.8
1492 0.47 1194 0.34 922 0.23
1.0
1476 0.52 1163 0.37 856 0.24
1.2
1458 0.57 1146 0.41 802 0.25
1.4
1458 0.63 1139 0.46 782 0.30
1.6
1139 0.52 844 0.36
1.8
844.3 0.42
CPG048 HIGH STATIC BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6
1894 0.66 1585 0.49
0.8
1839 0.71 1532 0.53 1223 0.37
1
17820.7314770.5511700.39
1.2
1786 0.80 1445 0.59 1115 0.40
1.4
1764 0.86 1426 0.64 1107 0.46
1.6
1446 0.72 1098 0.50
1.8
1099 0.56
CPG060 HIGH STATIC BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6
2219 0.95 1970 0.75
0.8
2215 1.04 1956 0.82 1697 0.62
1.0
22401.1519570.9016810.67
1.2
2260 1.26 1983 1.00 1683 0.74
1.4
2288 1.38 2009 1.10 1711 0.84
1.6
2032 1.21 1741 0.93
1.8
1776 1.04
CPG072 HIGH STATIC BELT DRIVE HORIZONTAL
CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP CFM BHP
0.6
2677 1.29 2486 1.07
0.8
2690 1.42 2529 1.20 2263 0.94
1.0
27401.6024711.2722461.0219720.79
1.2
2748 1.74 2518 1.44 2255 1.13 1970 0.87
1.4
2797 1.87 2562 1.59 2273 1.27 2025 0.99
1.6
2556 1.67 2314 1.40 2035 1.11
1.8
2342 1.50 2037 1.21
2.0
2137 1.35
NOTE
ESP, In
H
2
O
TURNS OPEN
012345
ESP, In
H
2
O
TURNS OPEN
012345
ESP, In
H
2
O
TURNS OPEN
012345
ESP, In
H
2
O
TURNS OPEN
012345
Tables represent dry coil without filter, to compensate for filter add 0.08" to measured E.S.P.
SCFM correction for wet coil = 4 %.
