8
A
B
C
D
CG
SUPPLY
RETURN
EVAPORATOR COIL
CONDENSER
COIL
COMPRESSOR
Y
X
Corner & Center of Gravity Locations
ABCD
CPG036045* 37 30 550 525 100 165 100 165
CPG036090* 37 30 560 535 100 170 100 170
CPG048090* 37 30 600 575 110 180 110 180
CPG048115* 37 30 605 580 110 180 110 180
CPG060090* 37 30 645 620 115 190 120 195
CPG060140* 37 30 655 630 120 195 120 195
CPG072140* 37 30 715 690 130 215 130 215
Operating
Weight
(lbs)
Corner Weights ( lbs )
* Weights shown are belt drive with no accessories.
Model
X
(in)
Y
(in)
Shipping
Weight
(lbs)
T
O
PREVENT
SEVERE
DAMAGE
TO
THE
BOTTOM
OF
THE
UNIT
,
DO
NOT
FORK
LIFT
UNIT
AFTER
WOOD
STRUTS
HAVE
BEEN
REMOVED
.
CAUTION
Bring condenser end of unit into alignment with the curb. With condenser end of the unit resting on curb member and using
curb as a fulcrum, lower opposite end of the unit until entire unit is seated on the curb. When a rectangular cantilever curb
is used, care should be taken to center the unit. Check for proper alignment and orientation of supply and return openings
with duct.
RIGGING REMOVAL
T
O
PREVENT
DAMAGE
TO
THE
UNIT
,
DO
NOT
ALLOW
CRANE
HOOKS
AND
SPREADER
BARS
TO
REST
ON
THE
ROOF
OF
THE
UNIT
.
CAUTION
Remove spreader bars, lifting cables and other rigging equipment.
