COOLING PERFORMANCE DATA
GSC130181C*
EXPANDED PERFORMANCE DATA COOLING OPERATION
MODEL: GSC130181C* / CA*F1824*6**+EEP
Outdoor Ambient Temperature
65 75 85 95 105 115
Entering Indoor Wet Bulb Temperature
IDB*Airflow 59636771596367715963677159 63 67715963677159636771
MBh 18.6 19.3 21.1 - 18.2 18.8 20.7 - 17.8 18.4 20.2 - 17.3 18.0 19.7 - 16.5 17.1 18.7 - 15.2 15.8 17.3 -
S/T 0.73 0.61 0.42 - 0.76 0.63 0.44 - 0.78 0.65 0.45 - 0.80 0.67 0.47 - 0.83 0.70 0.48 - 0.84 0.70 0.49 -
Delta T 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 19 16 12 - 17 15 11 -
675 KW 1.26 1.28 1.32 - 1.35 1.37 1.41 - 1.42 1.45 1.50 - 1.49 1.52 1.57 - 1.55 1.58 1.63 - 1.60 1.64 1.69 -
AMPS 4.6 4.7 4.9 - 5.0 5.1 5.2 - 5.4 5.5 5.7 - 5.7 5.9 6.0 - 6.1 6.2 6.4 - 6.4 6.6 6.8 -
HI PR 133 143 151 - 149 161 170 - 170 183 193 - 193 208 220 - 218 234 247 - 240 259 273 -
LO PR 62 66 72 - 65 69 76 - 68 72 79 - 71 76 83 - 75 79 87 - 77 82 90 -
MBh 18.1 18.7 20.5 - 17.7 18.3 20.0 - 17.2 17.9 19.6 - 16.8 17.4 19.1 - 16.0 16.6 18.1 - 14.8 15.3 16.8 -
S/T 0.70 0.58 0.40 - 0.72 0.61 0.42 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.80 0.66 0.46 - 0.80 0.67 0.46 -
Delta T 19 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 17 13 - 18 16 12 -
70 600 KW 1.25 1.27 1.31 - 1.34 1.36 1.40 - 1.41 1.44 1.49 - 1.48 1.51 1.56 - 1.54 1.57 1.62 - 1.59 1.62 1.67 -
AMPS 4.6 4.7 4.8 - 4.9 5.0 5.2 - 5.3 5.4 5.6 - 5.7 5.8 6.0 - 6.0 6.2 6.4 - 6.4 6.5 6.7 -
HI PR 132 142 150 - 148 159 168 - 168 181 191 - 191 206 218 - 215 232 245 - 238 256 270 -
LO PR 61 65 71 - 65 69 75 - 67 71 78 - 70 75 82 - 74 79 86 - 76 81 89 -
MBh 16.7 17.3 18.9 - 16.3 16.9 18.5 - 15.9 16.5 18.1 - 15.5 16.1 17.6 - 14.7 15.3 16.7 - 13.7 14.2 15.5 -
S/T 0.67 0.56 0.39 - 0.70 0.58 0.40 - 0.72 0.60 0.41 - 0.74 0.62 0.43 - 0.77 0.64 0.44 - 0.77 0.65 0.45 -
Delta T 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 20 17 13 - 19 16 12 -
525 KW 1.22 1.24 1.28 - 1.31 1.33 1.37 - 1.38 1.41 1.45 - 1.45 1.48 1.52 - 1.50 1.53 1.58 - 1.55 1.58 1.63 -
AMPS 4.5 4.6 4.7 - 4.8 4.9 5.1 - 5.2 5.3 5.5 - 5.5 5.7 5.8 - 5.9 6.0 6.2 - 6.2 6.3 6.5 -
HI PR 128 137 145 - 143 154 163 - 163 175 185 - 186 200 211 - 209 225 237 - 231 248 262 -
LO PR 59 63 69 - 63 67 73 - 65 69 76 - 68 73 79 - 72 76 83 - 74 79 86 -
MBh 18.9 19.5 21.1 22.6 18.5 19.0 20.6 22.1 18.1 18.6 20.1 21.6 17.6 18.1 19.6 21.1 16.7 17.2 18.6 20.0 15.5 16.0 17.3 18.5
S/T 0.83 0.75 0.56 0.36 0.86 0.77 0.58 0.38 0.89 0.79 0.60 0.39 0.91 0.82 0.62 0.40 0.95 0.85 0.64 0.41 0.96 0.86 0.65 0.42
Delta T21201611222016112220161122 20 17 11 22 20 16 11 20 19 15 11
675 KW 1.27 1.29 1.33 1.37 1.36 1.38 1.42 1.47 1.44 1.46 1.51 1.56 1.50 1.54 1.58 1.63 1.56 1.60 1.65 1.70 1.62 1.65 1.70 1.75
AMPS 4.7 4.8 4.9 5.1 5.0 5.1 5.3 5.5 5.4 5.5 5.7 5.9 5.8 5.9 6.1 6.3 6.1 6.3 6.5 6.7 6.5 6.6 6.8 7.1
HI PR 134 145 153 159 151 162 171 179 172 185 195 203 195 210 222 232 220 236 250 260 243 261 276 288
LO PR 62 66 72 77 66 70 76 81 68 73 79 85 72 76 83 89 75 80 87 93 78 83 91 96
MBh 18.4 18.9 20.5 22.0 18.0 18.5 20.0 21.5 17.5 18.0 19.5 21.0 17.1 17.6 19.1 20.5 16.2 16.7 18.1 19.4 15.0 15.5 16.8 18.0
S/T 0.79 0.71 0.54 0.35 0.82 0.74 0.56 0.36 0.84 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.81 0.61 0.39 0.91 0.82 0.62 0.40
Delta T22211712232117122321171223 21 17 12 23 21 17 12 21 19 16 11
75 600 KW 1.26 1.28 1.32 1.36 1.35 1.37 1.41 1.46 1.42 1.45 1.50 1.54 1.49 1.52 1.57 1.62 1.55 1.58 1.63 1.68 1.60 1.64 1.69 1.74
AMPS 4.6 4.7 4.9 5.0 5.0 5.1 5.2 5.4 5.4 5.5 5.7 5.9 5.7 5.9 6.0 6.3 6.1 6.2 6.4 6.7 6.4 6.6 6.8 7.0
HI PR 133 143 151 158 149 161 170 177 170 183 193 201 193 208 220 229 218 234 247 258 240 259 273 285
LO PR 62 66 72 76 65 69 76 81 68 72 79 84 71 76 83 88 75 79 87 92 77 82 90 95
MBh 17.0 17.5 18.9 20.3 16.6 17.1 18.5 19.8 16.2 16.7 18.0 19.4 15.8 16.3 17.6 18.9 15.0 15.4 16.7 17.9 13.9 14.3 15.5 16.6
S/T 0.77 0.69 0.52 0.33 0.79 0.71 0.54 0.35 0.81 0.73 0.55 0.35 0.84 0.75 0.57 0.37 0.87 0.78 0.59 0.38 0.88 0.79 0.60 0.38
Delta T23211712232117122321171223 21 18 12 23 21 17 12 21 20 16 11
525 KW 1.23 1.25 1.29 1.33 1.32 1.34 1.38 1.42 1.39 1.42 1.46 1.51 1.46 1.49 1.53 1.58 1.52 1.55 1.59 1.64 1.56 1.60 1.65 1.70
AMPS 4.5 4.6 4.7 4.9 4.8 4.9 5.1 5.3 5.2 5.4 5.5 5.7 5.6 5.7 5.9 6.1 5.9 6.1 6.2 6.5 6.3 6.4 6.6 6.8
HI PR 129 139 147 153 145 156 165 172 165 177 187 195 188 202 213 222 211 227 240 250 233 251 265 276
LO PR 60 64 70 74 63 67 73 78 66 70 76 81 69 73 80 85 72 77 84 89 75 80 87 93
* Entering Indoor Dry Bulb Temperature NOTE: Shaded area is ACCA (TVA) conditions
