SS-CKF50 www.goodmanmfg.com 5
P
RODUCT
S
PECIFICATIONS
EXPANDED COOLING DATA — CKF24-2* / A24-00-2RA (CONT.)
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB Airfl ow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
80
821
MBh 61.9 63.2 67.5 72.2 60.4 61.7 66.0 70.5 59.0 60.3 64.4 68.8 57.6 58.8 62.8 67.2 54.7 55.9 59.7 63.8 50.6 51.8 55.3 59.1
S/T 0.85 0.80 0.65 0.5 0.88 0.83 0.67 0.5 0.90 0.85 0.69 0.5 0.93 0.88 0.71 0.5 0.97 0.91 0.74 0.6 1.00 0.92 0.75 0.6
∆T 26 [-3] 25 [5] 22 [6] 17 [-8]26 [-3] 25 [6] 22 [6] 18 [6] 26 [-3] 25 [6] 22 [6] 18 [7] 27 [-7] 26 [2] 22 [2] 18 [-] 26 [-3] 25 [7] 22 [7] 17 [7] 25 [-4] 24 [7] 20 [7] 16 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
730
MBh 60.1 61.4 65.6 70.1 58.7 60.0 64.1 68.5 57.3 58.5 62.5 66.8 55.9 57.1 61.0 65.2 53.1 54.2 58.0 61.9 49.2 50.2 53.7 57.4
S/T 0.81 0.76 0.62 0.5 0.84 0.79 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.92 0.87 0.71 0.5 0.93 0.87 0.71 0.5
∆T 27 [-3] 26 [5] 23 [6] 18 [-8]28 [-2] 26 [6] 23 [6] 18 [6] 28 [-2] 26 [6] 23 [6] 18 [7] 28 [-7] 27 [2] 23 [2] 18 [-] 27 [-3] 26 [7] 23 [7] 18 [7] 26 [-3] 24 [7] 21 [7] 17 [8]
kW 5.30 5.42 5.59 5.8 5.72 5.85 6.04 6.2 6.09 6.22 6.43 6.7 6.41 6.56 6.78 7.0 6.69 6.84 7.08 7.3 6.93 7.09 7.33 7.6
Amps 11.2 11.4 11.7 12.0 11.9 12.1 12.4 12.8 12.7 13.0 13.3 13.7 13.4 13.7 14.1 14.6 14.2 14.5 14.9 15.4 14.9 15.2 15.6 16.1
Hi PR 171 184 194 202.4 192 206 218 227.1 218 234 248 258.2 248 267 282 294.1 279 300 317 330.9 308 332 351 365.6
Lo PR 52 56 61 64.6 55 59 64 68.3 57 61 67 71.0 60 64 70 74.6 63 67 73 78.1 65 70 76 80.8
639
MBh 55.4 56.7 60.5 64.7 54.2 55.3 59.1 63.2 52.9 54.0 57.7 61.7 51.6 52.7 56.3 60.2 49.0 50.1 53.5 57.2 45.4 46.4 49.5 53.0
S/T 0.78 0.73 0.60 0.4 0.81 0.76 0.62 0.5 0.83 0.78 0.64 0.5 0.86 0.81 0.66 0.5 0.89 0.84 0.68 0.5 0.90 0.84 0.69 0.5
∆T 252421172625211726252117262522172524211724232016
kW 5.17 5.28 0.80 5.6 5.58 5.70 5.89 6.1 5.94 6.07 6.27 6.5 6.25 6.39 6.61 6.8 6.52 6.67 6.89 7.1 6.75 6.91 7.14 7.4
Amps 10.9 11.1 11.4 11.8 11.6 11.8 12.2 12.5 12.4 12.7 13.0 13.4 13.1 13.4 13.8 14.2 13.8 14.1 14.5 15.0 14.5 14.8 15.3 15.8
Hi PR 166 178 188 196.3 186 200 211 220.3 211 227 240 250.5 241 259 274 285.3 271 291 308 321.0 299 322 340 354.6
Lo PR 51 54 59 62.7 54 57 62 66.2 56 59 65 68.8 58 62 68 72.3 61 65 71 75.8 63 67 74 78.4
85
821
MBh 62.9 64.2 67.2 71.7 61.5 62.7 65.6 70.0 60.0 61.2 64.1 68.4 58.6 59.7 62.5 66.7 55.6 56.7 59.4 63.4 51.5 52.5 55.0 58.7
S/T 0.89 0.86 0.78 0.6 0.93 0.89 0.81 0.7 0.95 0.92 0.83 0.7 0.98 0.94 0.85 0.7 1.00 0.98 0.89 0.7 1.00 0.99 0.89 0.7
∆T 28 [-2] 27 [6] 26 [6] 22 [-6]28 [-2] 28 [6] 26 [6] 23 [6] 28 [-2] 28 [6] 26 [7] 23 [7] 28 [-7] 28 [2] 26 [2] 23 [-] 28 [-2] 28 [7] 26 [7] 23 [7] 26 [-3] 26 [7] 24 [7] 21 [8]
kW 5.39 5.50 5.68 5.9 5.81 5.94 6.14 6.3 6.19 6.33 6.54 6.8 6.52 6.67 6.90 7.1 6.81 6.96 7.20 7.4 7.05 7.21 7.46 7.7
Amps 11.3 11.5 11.8 12.2 12.1 12.3 12.6 13.0 12.9 13.2 13.5 14.0 13.6 13.9 14.3 14.8 14.4 14.7 15.1 15.6 15.1 15.4 15.9 16.4
Hi PR 174 187 198 206.4 195 210 222 231.6 222 239 253 263.4 253 272 288 300.0 285 306 324 337.5 315 339 358 372.9
Lo PR 53 57 62 65.9 56 60 65 69.7 59 62 68 72.4 61 65 71 76.0 64 69 75 79.7 67 71 77 82.4
730
MBh 61.1 62.3 65.2 69.6 59.7 60.9 63.7 68.0 58.3 59.4 62.2 66.4 56.9 58.0 60.7 64.8 54.0 55.1 57.7 61.5 50.0 51.0 53.4 57.0
S/T 0.85 0.82 0.74 0.6 0.88 0.85 0.77 0.6 0.90 0.87 0.79 0.6 0.93 0.90 0.81 0.7 0.97 0.94 0.84 0.7 0.98 0.94 0.85 0.7
∆T 29 [-2] 29 [5] 27 [6] 23 [-5]29 [-2] 29 [6] 27 [6] 24 [6] 29 [-2] 29 [6] 27 [6] 24 [7] 30 [-7] 29 [2] 28 [2] 24 [-] 29 [-2] 29 [7] 27 [7] 23 [7] 27 [-3] 27 [7] 25 [7] 22 [8]
kW 5.34 5.46 5.64 5.8 5.77 5.89 6.09 6.3 6.14 6.28 6.49 6.7 6.47 6.62 6.84 7.1 6.75 6.90 7.14 7.4 6.99 7.15 7.39 7.7
Amps 11.2 11.5 11.8 12.1 12.0 12.2 12.5 12.9 12.8 13.1 13.4 13.9 13.5 13.8 14.2 14.7 14.3 14.6 15.0 15.5 15.0 15.3 15.8 16.3
Hi PR 172 186 196 204.4 193 208 220 229.3 220 237 250 260.8 251 270 285 297.1 282 303 320 334.2 312 335 354 369.3
Lo PR 53 56 61 65.3 56 59 65 69.0 58 62 67 71.7 61 65 71 75.3 64 68 74 78.9 66 70 77 81.6
639
MBh 56.4 57.5 60.2 64.2 55.1 56.2 58.8 62.8 53.8 54.8 57.4 61.3 52.5 53.5 56.0 59.8 49.9 50.8 53.2 56.8 46.2 47.1 49.3 52.6
S/T 0.82 0.79 0.71 0.6 0.85 0.82 0.74 0.6 0.87 0.84 0.76 0.6 0.90 0.87 0.78 0.6 0.93 0.90 0.81 0.7 0.94 0.91 0.82 0.7
∆T 29 [-2] 29 [5] 27 [5] 24 [-4]30 [-1] 29 [6] 28 [6] 24 [6] 30 [-1] 29 [6] 28 [6] 24 [7] 30 [-7] 30 [2] 28 [2] 24 [-] 30 [-1] 29 [7] 28 [7] 24 [7] 28 [-2] 27 [7] 26 [7] 22 [7]
kW 5.21 5.33 5.50 5.7 5.62 5.75 5.93 6.1 5.98 6.12 6.32 6.5 6.30 6.45 6.66 6.9 6.58 6.73 6.95 7.2 6.81 6.97 7.20 7.5
Amps 11.0 11.2 11.5 11.8 11.7 11.9 12.2 12.6 12.5 12.8 13.1 13.5 13.2 13.5 13.9 14.3 13.9 14.2 14.6 15.1 14.6 14.9 15.4 15.9
Hi PR 167 180 190 198.3 188 202 213 222.5 213 230 243 253.0 243 262 276 288.2 274 294 311 324.2 302 325 343 358.2
Lo PR 51 54 59 63.3 54 58 63 66.9 56 60 65 69.5 59 63 69 73.0 62 66 72 76.5 64 68 74 79.2
Shaded area refl ects ARI conditions IDB: Entering Indoor Dry Bulb Temperature kW = Total system power Amps = outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves. [ ] Designates metric equivalents
