SS-SSZ16 www.goodmanmfg.com 3
Product SPecificationS
SPecificationS
SSZ16
0241A
SSZ16
0361A
SSZ16
0481A
SSZ16
0601A
Capacities and Ratings
Nominal Cooling (BTU/h) 24,000 36,000 48,000 60,000
Nominal Heating (BTU/h) 24,000 36,000 48,000 60,000
Decibels 70 71 72 72
Compressor
RLA 13.4 14.1 19.8 25.6
LRA 58.3 77.0 109.0 118.0
Condenser Fan Motor
Horsepower
1
/
6
1
/
6
1
/
6
1
/
6
FLA 1.10 1.10 1.10 1.00
Refrigeration System
Refrigerant Line Size¹
Liquid Line Size (“O.D.)
⅜” ⅜” ⅜” ⅜”
Suction Line Size (“O.D.)
¾” ⅞” 1⅛” 1⅛”
Refrigerant Connection Size
Liquid Valve Size (“O.D.)
⅜” ⅜” ⅜” ⅜”
Suction Valve Size (“O.D.)
¾” ⅞” ⅞” ⅞”
Valve Connection Type Sweat Sweat Sweat Sweat
Refrigerant Charge 153 183 278 273
Electrical Data
Volts / Hz / Phase 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Minimum Circuit Ampacity ² 17.9 18.7 25.9 33
Max. Overcurrent Protection ³ 30 30 40 50
Min / Max Volts 197/253 197/253 197/253 197/253
Electrical Conduit Size
½” or ¾” ½” or ¾” ½” or ¾” ½” or ¾”
Ship Weight (lbs) 282 282 282 296
¹ Tested and rated in accordance with AHRI Standard 210/240
² Wire size should be determined in accordance with National Electrical Codes; extensive wire runs will require larger wire sizes
³ Must use time-delay fuses or HACR-type circuit breakers of the same size as noted.
Notes
• Always check the S&R plate for electrical data on the unit being installed.
• Installer will need to supply ⅞” to 1⅛” adapters for suction line connections.
• Unit is charged with refrigerant for 15’ of ⅜” liquid line. System charge must be adjusted per Installation Instructions Final
Charge Procedure.
• Installation of these units requires the specied TXV Kit to be installed on the indoor coil. THE SPECIFIED TXV IS DETERMINED
BY THE OUTDOOR UNIT NOT THE INDOOR COIL.
