4 www.goodmanmfg.com SS-SSZ16
Product SPecificationS
exPanded cooling data — SSZ160241a* / ca*f3636*6a* + txV / mBe1600**-1
Outdoor Ambient Temperature
65ºF 75ºF 85ºF 95ºF 105ºF 115ºF
Entering Indoor Wet Bulb Temperature
IDB* Airow 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71 59 63 67 71
70
984
MBh 23.5 24.4 26.7 - 23.0 23.8 26.1 - 22.4 23.2 25.5 - 21.9 22.7 24.8 - 20.8 21.5 23.6 - 19.3 20.0 21.9 -
S/T 0.78 0.65 0.45 - 0.81 0.68 0.47 - 0.83 0.69 0.48 - 0.86 0.72 0.50 - 0.89 0.74 0.52 - 0.90 0.75 0.52 -
∆T 17 15 11 - 17 15 11 - 17 15 11 - 18 15 12 - 17 15 11 - 16 14 11 -
kW 1.44 1.47 1.51 - 1.55 1.58 1.63 - 1.64 1.68 1.73 - 1.73 1.77 1.82 - 1.80 1.84 1.90 - 1.86 1.91 1.97 -
Amps 5.6 5.7 5.9 - 6.0 6.2 6.3 - 6.5 6.7 6.9 - 6.9 7.1 7.3 - 7.4 7.5 7.8 - 7.8 8.0 8.2 -
Hi PR 213 230 242 - 239 258 272 - 272 293 309 - 310 334 352 - 349 375 396 - 385 415 438 -
Lo PR 112 119 130 - 118 125 137 - 122 130 142 - 129 137 149 - 135 143 157 - 139 148 162 -
875
MBh 22.8 23.7 25.9 - 22.3 23.1 25.3 - 21.8 22.6 24.7 - 21.2 22.0 24.1 - 20.2 20.9 22.9 - 18.7 19.4 21.2 -
S/T 0.75 0.62 0.43 - 0.77 0.65 0.45 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.85 0.71 0.49 - 0.86 0.72 0.50 -
∆T 18 15 12 - 18 16 12 - 18 16 12 - 18 16 12 - 18 16 12 - 17 15 11 -
kW 1.43 1.46 1.50 - 1.54 1.57 1.62 - 1.63 1.67 1.72 - 1.72 1.75 1.81 - 1.79 1.83 1.89 - 1.85 1.89 1.95 -
Amps 5.5 5.7 5.8 - 6.0 6.1 6.3 - 6.5 6.6 6.8 - 6.9 7.0 7.3 - 7.3 7.5 7.7 - 7.7 7.9 8.2 -
Hi PR 211 227 240 - 237 255 269 - 270 290 306 - 307 330 349 - 345 372 392 - 382 411 434 -
Lo PR 110 117 128 - 117 124 136 - 121 129 141 - 127 136 148 - 133 142 155 - 138 147 160 -
766
MBh 21.1 21.8 23.9 - 20.6 21.3 23.4 - 20.1 20.8 22.8
- 19.6 20.3 22.3 - 18.6 19.3 21.1 - 17.3 17.9 19.6 -
S/T 0.72 0.60 0.42 - 0.75 0.62 0.43 - 0.76 0.64 0.44 - 0.79 0.66 0.46 - 0.82 0.68 0.47 - 0.83 0.69 0.48 -
∆T 18 16 12 - 18 16 12 - 18 16 12 - 19 16 12 - 18 16 12 - 17 15 11 -
kW 1.39 1.42 1.47 - 1.50 1.53 1.58 - 1.59 1.63 1.68 - 1.67 1.71 1.76 - 1.74 1.78 1.84 - 1.80 1.84 1.90 -
Amps 5.4 5.5 5.7 - 5.8 5.9 6.1 - 6.3 6.4 6.6 - 6.7 6.9 7.1 - 7.1 7.3 7.5 - 7.5 7.7 7.9 -
Hi PR 205 220 233 - 230 247 261 - 261 281 297 - 298 320 338 - 335 360 381 - 370 398 421 -
Lo PR 107 114 124 - 113 120 131 - 118 125 137 - 124 131 143 - 129 138 150 - 134 142 156 -
75
984
MBh 23.9 24.6 26.7 28.6 23.4 24.1 26.0 27.9 22.8 23.5 25.4 27.3 22.2 22.9 24.8 26.6 21.1 21.8 23.6 25.3 19.6 20.2 21.8 23.4
S/T 0.89 0.80 0.60 0.39 0.92 0.82 0.62 0.40 0.94 0.85 0.64 0.41 0.98 0.87 0.66 0.42 1.00 0.91 0.69 0.44 1.00 0.91 0.69 0.44
∆T 20 18 15 10 20 19 15 10 20 19 15 10 20 19 15 11 20 18 15 10 18 17 14 10
kW 1.45 1.48 1.53 1.58 1.56 1.59 1.64 1.70 1.66 1.69 1.75 1.81 1.74 1.78 1.84 1.90 1.82 1.86 1.92 1.98 1.88 1.92 1.99 2.05
Amps 5.6 5.8 5.9 6.2 6.1 6.2 6.4 6.6 6.6 6.7 6.9 7.2 7.0 7.2 7.4 7.7 7.4 7.6 7.9 8.1 7.9 8.0 8.3 8.6
Hi PR 215 232 245 255 242 260 275 287 275 296 312 326 313 337 356 371 352 379 400 418 389 419 442 461
Lo PR 113 120 131 139 119 127 138 147 124 132 144 153 130 138 151 161 136 145 158 168 141 150 164 174
875
MBh 23.2 23.9 25.9 27.8 22.7 23.4 25.3 27.1 22.1 22.8 24.7 26.5 21.6 22.2 24.1 25.8 20.5 21.1 22.9 24.5 19.0 19.6 21.2 22.7
S/T 0.85 0.76 0.57 0.37 0.88 0.79 0.59 0.38 0.90 0.81 0.61 0.39 0.93 0.83 0.63 0.41 0.97 0.86 0.65 0.42 0.97 0.87 0.66 0.42
∆T 21 19 16 11 21 19 16 11
21 19 16 1
1 21 19 16 11 21 19 16 11 19 18 15 10
kW 1.44 1.47 1.51 1.56 1.55 1.58 1.63 1.68 1.64 1.68 1.73 1.79 1.73 1.77 1.83 1.89 1.80 1.84 1.90 1.97 1.86 1.91 1.97 2.04
Amps 5.6 5.7 5.9 6.1 6.0 6.2 6.3 6.6 6.5 6.7 6.9 7.1 6.9 7.1 7.3 7.6 7.4 7.5 7.8 8.1 7.8 8.0 8.2 8.5
Hi PR 213 230 242 253 239 258 272 284 272 293 309 323 310 334 352 368 349 375 396 413 385 415 438 457
Lo PR 112 119 130 138 118 125 137 146 122 130 142 152 129 137 149 159 135 143 157 167 139 148 162 173
766
MBh 21.4 22.1 23.9 25.6 20.9 21.6 23.3 25.0 20.4 21.0 22.8 24.4 19.9 20.5 22.2 23.8 18.9 19.5 21.1 22.7 17.5 18.1 19.6 21.0
S/T 0.82 0.73 0.55 0.36 0.85 0.76 0.57 0.37 0.87 0.78 0.59 0.38 0.90 0.80 0.61 0.39 0.93 0.83 0.63 0.41 0.94 0.84 0.64 0.41
∆T 21 19 16 11 21 20 16 11 21 20 16 11 21 20 16 11 21 19 16 11 20 18 15 10
kW 1.40 1.43 1.48 1.53 1.51 1.54 1.59 1.64 1.60 1.64 1.69 1.75 1.69 1.72 1.78 1.84 1.76 1.80 1.85 1.92 1.82 1.86 1.92 1.98
Amps 5.4 5.6 5.7 5.9 5.9 6.0 6.2 6.4 6.3 6.5 6.7 6.9 6.8 6.9 7.1 7.4 7.2 7.3 7.6 7.9 7.6 7.8 8.0 8.3
Hi PR 207 223 235 245 232 250 264 275 264 284 300 313 301 324 342 357 338 364 385 401 374 402 425 443
Lo PR 108 115 126 134 114 122 133 141 119 126 138 147 125 133 145 154 131 139 152 162 135 144 157 167
IDB: Entering Indoor Dry Bulb Temperature Shaded area is ACCA (TVA) conditions kW = Total system power Amps = outdoor unit amps (comp.+fan)
High and low pressures are measured at the liquid and suction service valves. Design Subcooling 7 ± 2 °F @ the liquid service valve; AHRI 95 °F test conditions
